Question

What are the possible ways to solve a stack overflow caused by an recursive algorithm?

Example

I'm trying to solve Project Euler problem 14 and decided to try it with a recursive algorithm. However, the program stops with a java.lang.StackOverflowError. Understandably. The algorithm indeed overflowed the stack because I tried to generate a Collatz sequence for a very large number.

Solutions

So I was wondering: what standard ways are there to solve a stack overflow assuming your recursive algorithm was written correctly and would always end up overflowing the stack? Two concepts that came to mind were:

  1. tail recursion
  2. iteration

Are ideas (1) and (2) correct? Are there other options?

Edit

It would help to see some code, preferably in Java, C#, Groovy or Scala.

Perhaps don't use the Project Euler problem mentioned above so it won't get spoiled for others, but take some other algorithm. Factorial maybe, or something similar.

Lernkurve
  • 817
  • 1
  • 7
  • 14
  • 3
    Iteration. Memoisation – James Apr 11 '13 at 10:50
  • @James. Thank you. I understand iteration. I haven't quite understood memoisation. Care to add an answer explaining the latter or adding a link you found suitable for a beginner? – Lernkurve Apr 11 '13 at 10:55
  • Memoisation means remembering intermediate results to avoid calculating them repeatedly. See the wikipedia page about it for code examples. – Joeri Sebrechts Apr 11 '13 at 11:09
  • 2
    Obviously, Memoization only works when there actually *is* repeated calculation. – Jörg W Mittag Apr 11 '13 at 12:06
  • 2
    also worth noting that not all language implementations can do tail recursion optimizations anyway – jk. Apr 11 '13 at 12:22
  • "generate a Collatz sequence" recursively? Why? I guess doing this iteratively is (especially in a non-functional language like Java) very simple. The Java code won't be much longer that the 10 lines of pseudo code on http://en.wikipedia.org/wiki/Collatz_conjecture – Doc Brown Apr 11 '13 at 12:47
  • 2
    This would probably be better solved with corecursion than recursion. – Jörg W Mittag Apr 11 '13 at 13:31
  • 3
    If you are working from the number less than 1,000,000 and going to 1, the answer to this question involves about 500 steps to reach 1. This should not tax recursion given a small stack frame. --- If you are attempting to solve starting at 1, then following it to 2, 4, 8, 16, {5,32} and go up from there, you are doing it wrong. –  Apr 11 '13 at 13:51
  • Recursion to iteration: http://stackoverflow.com/questions/1549943/design-patterns-for-converting-recursive-algorithms-to-iterative-ones, http://stackoverflow.com/questions/159590/way-to-go-from-recursion-to-iteration, https://www.google.com/search?q=convrt+recursion+to+iteration – Jan Doggen Apr 11 '13 at 14:07
  • @JörgWMittag: I'm not quite sure how corecursion would prevent the stack overflow. Could you explain? – FrustratedWithFormsDesigner Apr 11 '13 at 14:11
  • @DocBrown: Why recursively? Just for practicing recursion. :-) I had first solved it iteratively. – Lernkurve Apr 11 '13 at 14:36
  • @MichaelT: You are correct, of course. The stack frame count is small enough with numbers less than one million. I just mentioned the Collatz problem to give some more context. But that probably was a bad idea because it has nothing to do with the actual question. But thank you for the feedback! – Lernkurve Apr 11 '13 at 14:42
  • possible duplicate: http://programmers.stackexchange.com/questions/194646/what-methods-are-there-to-avoid-a-stack-overflow-in-a-recursive-algorithm :) – Ben Lee Apr 15 '13 at 21:02
  • I just tried this, for practice, and I found that the stack overflow exceptions I got weren't legitimate; they were caused by the value getting high enough to overflow MAXINT and wrap around. Changing to 64-bit integers got rid of the stack-breaking. – Mason Wheeler Feb 11 '14 at 04:30
  • The Project Euler problem can be solved using a simple iteration assuming true the Collatz conjecture: while (n > 1) { if Odd(n) { n = 3 * n + 1; } else { n = n / 2; } } –  Feb 11 '14 at 03:21
  • @MasonWheeler: You might try to run the code in Swift. Overflow will crash, guaranteed. And the first number leading to a 64 bit overflow isn't very large. – gnasher729 Feb 19 '15 at 00:50

8 Answers8

40

Tail call optimization is present in many languages and compilers. In this situation, the compiler recognizes a function of the form:

int foo(n) {
  ...
  return bar(n);
}

Here, the language is able to recognize that the result being returned is the result from another function and change a function call with a new stack frame into a jump.

Realize that the classic factorial method:

int factorial(n) {
  if(n == 0) return 1;
  if(n == 1) return 1;
  return n * factorial(n - 1);
}

is not tail call optimizatable because of the inspection necessary on the return. (Example source code and compiled output)

To make this tail call optimizeable,

int _fact(int n, int acc) {
    if(n == 1) return acc;
    return _fact(n - 1, acc * n);
}

int factorial(int n) {
    if(n == 0) return 1;
    return _fact(n, 1);
}

Compiling this code with gcc -O2 -S fact.c (the -O2 is necessary to enable the optimization in the compiler, but with more optimizations of -O3 it gets hard for a human to read...)

_fact(int, int):
    cmpl    $1, %edi
    movl    %esi, %eax
    je  .L2
.L3:
    imull   %edi, %eax
    subl    $1, %edi
    cmpl    $1, %edi
    jne .L3
.L2:
    rep ret

(Example source code and compiled output)

One can see in segment .L3, the jne rather than a call (which does a subroutine call with a new stack frame).

Please note this was done with C. Tail call optimization in Java is hard and depends on the JVM implementation (that said, I haven't seen any that do it, because it is hard and implications of the required Java security model requiring stack frames - which is what TCO avoids) -- tail-recursion + java and tail-recursion + optimization are good tag sets to browse. You may find other JVM languages are able to optimize tail recursion better (try clojure (which requires the recur to tail call optimize), or scala).

That said,

There is a certain joy in knowing that you wrote something right - in the ideal way that it can be done.
And now, I'm going to get some scotch and put on some German electronica...


To the general question of "methods to avoid a stack overflow in a recursive algorithm"...

Another approach is to include a recursion counter. This is more for detecting infinite loops caused by situations beyond one's control (and poor coding).

The recursion counter takes the form of

int foo(arg, counter) {
  if(counter > RECURSION_MAX) { return -1; }
  ...
  return foo(arg, counter + 1);
}

Each time you make a call, you increment the counter. If the counter gets too big, you error out (in here, just a return of -1, though in other languages you may prefer to throw an exception). The idea is to prevent worse things from happening (out of memory errors) when doing a recursion that is much deeper than expected and likely an infinite loop.

In theory, you shouldn't need this. In practice, I've seen poorly written code that has hit this because of a plethora of small errors and bad coding practices (multithreaded concurrency issues where something changes something outside the method that makes another thread go into an infinite loop of recursive calls).


Use the right algorithm and solve the right problem. Specifically for the Collatz Conjecture, it appears that you are trying to solve it in the xkcd way:

XKCD #710

You are starting at a number and doing a tree traversal. This rapidly leads to a very large search space. A quick run to calculate the number of iterations for the correct answer results in about 500 steps. This shouldn't be an issue for recursion with a small stack frame.

While knowing the recursive solution is not a bad thing, one should also realize that many times the iterative solution is better. A number of ways of approaching converting a recursive algorithm to an iterative one can be seen on Stack Overflow at Way to go from recursion to iteration.

  • 1
    I had come across that xkcd cartoon today while surfing the web. :-) Randall Munroe's cartoons are a delight. – Lernkurve Apr 11 '13 at 15:26
  • @Lernkurve I noticed the addition of the code edit after I had started writing this (and posted). Do you need other code samples for this? –  Apr 11 '13 at 15:58
  • No, not at all. It's perfect. Thanks a bunch for asking! – Lernkurve Apr 11 '13 at 18:03
  • May I suggest adding this cartoon too: http://imgs.xkcd.com/comics/functional.png – Ellen Spertus Feb 23 '15 at 19:45
  • @espertus thank you. I've added it (cleaned up some source generation and added a bit more) –  Feb 24 '15 at 01:36
  • Every tail-call loop I've seen is easily converted to an iterative loop. OP could write a tail-call solution for Problem #14, but why not go a step further and write the iterative version? – user2023861 Feb 05 '16 at 19:17
  • @user2023861 because in some languages, writing the iterative solution is harder than writing the recursive (TCO) solution. And in languages that support both and are both fairly equivalent in effort to do, it then becomes a question of what is easier to understand for the author and for the maintainer. Within scala and HotSpot JVM for example, the JIT will find it easier to optimize a small function all that is reclusive (and called lots) over a for loop that is part of a larger function call (which it may not even do). –  Feb 05 '16 at 23:15
17

Keep in mind that the language implementation must support tail recursion optimization. I don't think the major java compilers do.

Memoization means you remember the result of a calculation rather than recalculating it every time, like:

collatz(i):
    if i in memoized:
        return memoized[i]

    if i == 1:
        memoized[i] = 1
    else if odd(i):
        memoized[i] = 1 + collatz(3*i + 1)
    else
        memoized[i] = 1 + collatz(i / 2)

    return memoized[i]

When you're calculating every sequence less than a million, there's going to be a lot of repetition at the end of the sequences. Memoization makes it a quick hash table lookup for previous values instead of having to make the stack deeper and deeper.

Karl Bielefeldt
  • 146,727
  • 38
  • 279
  • 479
  • 1
    Very understandable explanation of memoization. Above all, thank you for illustrating it with a code snippet. Also, "there's going to be a lot of repetition at the end of the sequences" made things clear for me. Thank you. – Lernkurve Apr 11 '13 at 14:56
10

I'm surprised that no one has mentioned trampolining yet. A trampoline (in this sense) is a loop that iteratively invokes thunk-returning functions (continuation passing style) and can be used to implement tail-recursive function calls in a stack-oriented programming langauge.

This StackOverflow question goes into quite a bit more detail about various implementations of trampolining in Java: Handling StackOverflow in Java for Trampoline

Rein Henrichs
  • 13,112
  • 42
  • 66
  • I thought of this right away as well. Trampolines are a method of for performing tail call optimization, so people are (sorta-almost-maybe) saying it. +1 For the specific reference. – Steven Evers Apr 12 '13 at 00:49
6

If you are using a language and compiler that recognize tail recursive functions and handles them properly (i.e. "replaces the caller in place with the callee"), then yeah, the stack should not grow out of control. This optimization essentially reduces a recursive method to an iterative one. I don't think Java does this, but I know that Racket does.

If you go with an iterative approach, rather than a recursive approach, you are removing much of the need to remember where calls are coming from, and practically eliminating the chance of a stack overflow (from recursive calls anyway).

Memoization is great and can cut down on the overall number of method calls by looking up previously calculated results in a cache, given that your overall calculation will incur many smaller, repeated calculations. This idea is great -- it's also independent of whether or not you are using an iterative approach or a recursive one.

3

you could create an Enumeration that will replace the recursion... here is an example for calculating faculty doing that... (wont work for big numbers as i only used long in the example :-))

public class Faculty
{

    public static IEnumerable<long> Faculties(long n)
    {
        long stopat = n;

        long x = 1;
        long result = 1;

        while (x <= n)
        {
            result = result * x;
            yield return result;
            x++;
        }
    }
}

even if this is not memoization, this way you will void a stack overflow


EDIT


I am sorry if I upset some of you. My only intention was to show a way how to avoid a stack overflow. I probably should have written a full code example instead of just a small piece of a quickly written and rough code excerpt.

The following code

  • avoids recursion as I use calculate the required values iteratively.
  • includes memoization as Values already calculated are stored away and retrieved if already calculated
  • also includes a stopwatch, so you can see that memoization works properly

...umm... if you run it make sure you set your command shell window to have a buffer of 9999 lines... the usual 300 will not be enough to run through the results of the below program...

using System;
using System.Collections.Generic;
using System.Diagnostics;
using System.Linq;
using System.Numerics;
using System.Text;
using System.Threading.Tasks;
using System.Timers;

namespace ConsoleApplication1
{
    class Program
    {
        static Stopwatch w = new Stopwatch();
        static Faculty f = Faculty.GetInstance();

        static void Main(string[] args)
        {
            Out(5);
            Out(10);
            Out(-5);
            Out(0);
            Out(1);
            Out(4);
            Out(29);
            Out(30);
            Out(20);
            Out(10000);
            Out(20000);
            Out(19999);
            Console.ReadKey();
        }

        static void Out(BigInteger n)
        {
             try
            {
                w.Reset();
                w.Start();
                var x = f.Calculate(n);
                w.Stop();
                var time = w.ElapsedMilliseconds;
                Console.WriteLine(String.Format("{0} ({2}ms): {1}", n, x, time));
            }
            catch (ArgumentException e)
            {
                Console.WriteLine(e.Message);
            }

            Console.WriteLine("\n\n");
       }
    }

I declare * 1 static variable "instance" in the Faculty class to a store a singleton. That way as long as your program is running, whenever you "GetInstance()" of the class you get the instance that has stored all values already calculated. * 1 static SortedList which will hold all the values already calculated

In the constructor I also add 2 special values of the list 1 for inputs 0 and 1.

    public class Faculty
    {
        private static SortedList<BigInteger, BigInteger> _values;
        private static Faculty _faculty {get; set;}

        private Faculty ()
        {
            _values = new SortedList<BigInteger, BigInteger>();
            _values.Add(0, 1);
            _values.Add(1, 1);
        }

        public static Faculty GetInstance() {
            _faculty = _faculty ?? new Faculty();
            return _faculty;
        }

        public BigInteger Calculate(BigInteger n)
        {
            // check if input is smaller 0
            if (n < 0)
                throw new ArgumentException(" !!! Faculty is not defined for values < 0 !!!");

            // if value is not already calculated => do so
            if(!_values.ContainsKey(n))
                Faculties(n);

            // retrieve n! from Sorted List
            return _values[n];
        }

        private static void Faculties(BigInteger n)
        {
            // get the last calculated values and continue calculating if the calculation for a bigger n is required
            BigInteger i = _values.Max(x => x.Key),
                           result = _values[i];

            while (++i <= n)
            {
                CalculateNext(ref result, i);
                // add value to the SortedList if not already done
                if (!_values.ContainsKey(i))
                    _values.Add(i, result);
            }
        }

        private static void CalculateNext(ref BigInteger lastresult, BigInteger i) {

            // put in whatever iterative calculation step you want to do
            lastresult = lastresult * i;

        }
    }
}
Ingo
  • 274
  • 2
  • 5
  • 5
    technically this is iteration as you completely removed any recursion – ratchet freak Apr 11 '13 at 12:03
  • that it is :-) and it memoizes the results within the methods variables between each calculation step – Ingo Apr 11 '13 at 12:07
  • 2
    I think you misunderstand memoisation, which is when faculties(100) is called the first time it calculates the result and stores it in a hash and returned, then when it is called again the stored result is returned – ratchet freak Apr 11 '13 at 12:21
  • @jk. To his credit, he never actually says this is recursive. – Neil Apr 11 '13 at 14:13
  • even if this is not memoization, this way you will void a stack overflow – Ingo Apr 11 '13 at 15:13
  • It isn't necessary to mention memoization when one is showing recursion to iteration (a valid technique). Realizing that this is not CodeReview.SE... what is `stopat` intended to be used for? What happens if you pass in 0 (0! = 1)? What does this actually do? is it useful? why are you returning an enumerable to what appears to be a factorial algorithm? –  Apr 11 '13 at 16:49
  • sorry if i upset any of you. this afternoon (at work) i just scribbled down a quick idea towards solving his problem. i did a mistake and i apologize. i hope my edit will calm your minds – Ingo Apr 11 '13 at 20:35
2

As for Scala, you can add the @tailrec annotation to a recursive method. This way the compiler ensures that tail call optimization actually took place:

So this won't compile (factorial):

@tailrec
def fak1(n: Int): Int = {
  n match {
    case 0 => 1
    case _ => n * fak1(n - 1)
  }
}

the error message is:

scala: could not optimize @tailrec annotated method fak1: it contains a recursive call not in tail position

On the other hand:

def fak3(n: Int): Int = {
  @tailrec
  def fak3(n: Int, result: Int): Int = {
    n match {
      case 0 => result
      case _ => fak3(n - 1, n * result)
    }
  }

  fak3(n, 1)
}

compiles, and tail call optimization took place.

Beryllium
  • 121
  • 3
1

One possibility which have not been mentioned yet is to have recursion, but without using a system stack. Of course you can overflow your heap as well, but if your algorithm really need backtracking in one form or another (why using recursion at all otherwise?), you've got no choice.

There are stackless implementations of some languages, e.g. Stackless Python.

SK-logic
  • 8,497
  • 4
  • 25
  • 37
0

Another solution would be to simulate your own stack and not rely on the implementation of the compiler + runtime. This is not a simple solution nor a fast one but theoretically you'll get StackOverflow only when you're out of memory.

Random42
  • 10,370
  • 10
  • 48
  • 65
