Seamarks/Sectored and Directional Lights

The tags defined on this page will render in various nautical charts.

A list of attributes applicable to lights may be found at: light attributes.

Light	Rendering	Tags
Sectored		seamark:light:1:character=Fl seamark:light:1:colour=green seamark:light:1:group=2 seamark:light:1:period=10 seamark:light:1:sector_end=260 seamark:light:1:sector_start=230 seamark:light:2:character=Fl seamark:light:2:colour=white seamark:light:2:group=2 seamark:light:2:period=10 seamark:light:2:sector_end=280 seamark:light:2:sector_start=260 seamark:light:3:character=Fl seamark:light:3:colour=red seamark:light:3:group=2 seamark:light:3:period=10 seamark:light:3:sector_end=310 seamark:light:3:sector_start=280 seamark:type=light_major
Directional		seamark:light:1:category=directional seamark:light:1:character=F seamark:light:1:colour=green seamark:light:1:orientation=263 seamark:light:2:category=directional seamark:light:2:character=Al seamark:light:2:colour=green;white seamark:light:2:orientation=267 seamark:light:3:category=directional seamark:light:3:character=F seamark:light:3:colour=white seamark:light:3:orientation=270 seamark:light:4:category=directional seamark:light:4:character=Al seamark:light:4:colour=red;white seamark:light:4:orientation=273 seamark:light:5:category=directional seamark:light:5:character=F seamark:light:5:colour=red seamark:light:5:orientation=277 seamark:type=light_major

  180°
90°  270°
 0°/360°
