I've been looking at the SM74611 Smart Bypass Diode from Texas Instruments and am very impressed with the reported reverse leakage current (0.3uA at 25C). Considering the device has a N-Channel FET, 0.3uA of Drain-Source leakage current @ 25C is nothing to scoff at considering that most FETs usually have a Drain-Source leakage current of 1uA.

At first I thought this discrepancy could easily be explained by finding the right FET online, but I quickly realized that I would spend days trying to find said part as this parameter is usually not specified in the parametric searches.

Does a sub-1uA Drain-Source leakage current FET exist, or is there some trick to get a smaller leakage current from a typical FET?

TRISAbits
  • 1,348
  • 1
  • 13
  • 25

7 Answers7

8

I have recently characterized several signal and even power mosfet devices (e.g. FDP6030BL in TO220 case), at room temperature, using an Agilent B1500. To my extreme surprise, the OFF-state (Vgs=0) drain current in most of the cases (even in power devices!) was between 0.1 pA and 10 pA (at about Vds=20V), despite it was 1uA in all the datasheets. The worst ones had 100pA. Still, this does not mean that all the devices will show such good OFF-state performances!

Nicola
  • 81
  • 1
  • 1
  • 1
    This confirms Spehro statement that the datasheet figures tend to be conservative. Thanks for sharing the info: it's always great to get new insights on this kind of stuff. – TRISAbits Feb 25 '15 at 18:28
7

There's no guarantee with your device.. it's 300nA at 25C and 3.3uA at high temperature typical. In fact, if the distribution of leakage is Gaussian (a rather big "if"), you'd expect 1uA would be a reasonable guess for the maximum (\$3 \sigma\$).

enter image description here

If you want low typical leakage, you should pick a device that's no bigger (in terms of drain current rating) than you need, and one with a relatively high \$V_{TH}\$ rather than a ginormous MOSFET rated for 1.8V drive. Some small signal MOSFETs are typically 1pA at 25°C, which is 300,000 times better than the SM74611.

Most people don't care about leakage that much, so the maximum figures tend to be conservative. I don't know any alternative to looking at data sheets to see what is guaranteed or specified as typical. You can always measure it yourself, but the next batch could (in theory anyway) be wildly different. The same part number from a different manufacturer probably will be different.

Spehro Pefhany
  • 376,485
  • 21
  • 320
  • 842
  • 1pA! I've never heard nor seen such low leakage current. Do you have a specific part number or a manufacturer in mind: I'm very curious to read up on what kind of MOSFET this is. – TRISAbits Feb 03 '14 at 16:39
  • 1
    Not sure I recall.. Advanced Linear has a number of MOSFET arrays with 10pA typical @25°C (eg. ALD110808). The 2N4417 JFET has a typical drain-source leakage of 200fA! – Spehro Pefhany Feb 03 '14 at 18:23
  • It looks like ON Semiconductor provides a Ids vs Vds curve for Vgs = 0v (OFF state leakage). See figure 6 of the [NTJD4001N](http://www.onsemi.com/pub_link/Collateral/NTJD4001N-D.PDF) for an example. This curve indicates that leakage current is around 20nA, and that's for a junction temp of 125C. For lower temps, it would be smaller. – Andrew Martin Sep 20 '16 at 18:32
6

Old question, but I came across this discussion when encountering the same problem as the OP. So for posterity, I'll contribute what I've found.

It looks like ON Semiconductor provides a Ids vs Vds curve for Vgs = 0v (OFF state leakage) for its family of small signal FETs (unlike other vendors). See figure 6 of the NTJD4001N for an example. This curve indicates that leakage current is around 20nA, and that's for a junction temp of 125C. For lower temps, it would be smaller.

Now the same datasheet also indicates that the max leakage drain current (Idss) is 1uA, which I have seen on fairchild nFET datasheets as well. So keep in mind that figure 6 curve is likely a typical behavior curve. But in my mind you would only ever get 1uA of leakage under worst case scenarios (high temp, large Vds, etc).

Andrew Martin
  • 375
  • 3
  • 8
5

Low off state leakage is not a typical circuit requirement for power MOSFETs. Particularly with a low or even zero drain to source voltage VDS. Most datasheets specify the leakage with a VDS close to the VDS breakdown of the transistor as this type of leakage is much more important for power switching such as DC/DC conversion. Consider that 1A of on current versus 1uA of off current is 6 decades or 120 dB; that's a dramatic change in current flow; asking for more seems excessive.

It is frustrating that there don't seem to MOSFETs designed for low leakage analog switching. You might consider an analog switch. The lowest leakage device I could find is the MAX326/MAX327. These have on resistances of about 2k so they are not acceptable for anything but low current switching.

MOSFETS with low leakage specifications do exist but they are part of a solid state relay. This means they come with the advantage of back to back devices for bi-directional voltage blocking and optical isolation of the "gate" from the switched nodes. There are many disadvantages like slow switching speed, higher cost, fewer choices, and typically more capacitance on the switched nodes for the same Ron as a discrete MOSFET.

You can decrease drain to source leakage by decreasing the gate voltage. Most power MOSFETS are rated to take +/-10 to +/-20 V gate to source. Driving the gate negative on an n-channel device will decrease leakage. A more negative gate voltage further depletes the channel of electrons. Thermally created electrons that are responsible for leakage are driven away from the channel by the gate's electric field and into the body (which is connected to the source in a discrete FET). There is a lot of research and data that show this sub-threshold conduction effect. All most all of it is directed at fine line IC processing where sub-threshold leakage of millions of transistors can add up to a large static current.

Something you might not have control over is temperature of the FET, but lower temperature means lower leakage.

Don't forget that there maybe p-n junction between the gate and the source (to protect the gate) so driving the gate negative may increase gate to source leakage.

jherbold
  • 348
  • 2
  • 5
4

The BSC067N06LS3G has a typical leakage of 0.1uA. It's 50A and 60V rated too. The BSC093N04LSG is the same. Maybe you need to look at Infineon MOSFETs. These are all typical values. maximum values are 1uA. Your device is 0.3uA typically too.

There is no trick to reducing leakage current by the way - you've just got to find the right device.

Andy aka
  • 434,556
  • 28
  • 351
  • 777
  • If only Digikey/Mouser/etc. had a leakage current figure for me to find these parts. The MOSFETs you pointed at are very interesting: I wonder who other than Infineon makes low leakage current MOSFETs; it would be nice to compare them with the competition. – TRISAbits Feb 03 '14 at 16:45
  • Distinguish between "low leakage" and "guaranteed to be low leakage". – Spehro Pefhany Feb 03 '14 at 18:03
  • 1
    @SpehroPefhany Good point. – TRISAbits Feb 04 '14 at 05:25
1

Nexperia published an app note about FET leakage, which mentioned several low-leakage FETs specified down to 25nA @ 5V and 50nA @ 1.8V:

  • PMZ950UPEL P-ch
  • PMZ600UNEL N-ch
  • see others in Table 1 on page 7 of the same document

https://assets.nexperia.com/documents/application-note/AN90009.pdf

Also, Infineon has several FETs with drain-to-source leakage specified down to 0.1uA:

  • BSS 223PW P-ch
  • BSS138W N-ch

https://www.infineon.com/cms/en/product/power/mosfet/small-signal-small-power

alexei
  • 241
  • 2
  • 5
1

If you want a low leakage FET in a manageable package...

While the Infineon parts that Andy mentions in his answer do have good guaranteed leakage specs, they're in relatively hard to work with near-leadless (flat lead) packages, and the Nexperia parts mentioned in alexei's answer are worse. Worse yet, at the time of writing this answer, the BSS138 is experiencing supply shortages. That said, there's still a "jellybean" option here, namely the BSS123. It's specified at 10nA IDSS maximum at a VDS of 20V, across multiple vendors (ON Semi and Diodes are the ones I checked, as Nexperia lists the part as NRND on their end).

ThreePhaseEel
