RAM1K18 IP - Constant Busy 'z' and Reading "0" on data bus

Question

I am working with an IGLOO2 device and attempting to instantiate a RAM1K18 IP into my design using the SmartDesign Tool in Libero 2023.1. I have a basic testbench in which I establish an address, and attempt to write to it, and read back the data. However, in sim I see both "A_DOUT" and "B_DOUT" all 0's. The "Busy" signal is constant 'z'

I have tried extending my sim to 1ms, which I feel is plenty of time, however the signals remain. I have ported a design onto HW with the same IP using a similar method of writing / reading and am seeing 0's for my DOUT signals there as well though there I see constant '0' instead of constant 'z'.

SmartDesign Instantiation:

Testbench snippet:

--Generate the test stimulus
tb1 : process
begin
    --Pre reset
    wait for CLK_PERIOD*10;

    --Toggle reset
    wait for CLK_PERIOD*5;
    RESET_N <= '0';
    wait for CLK_PERIOD;
    RESET_N <= '1';
    wait for CLK_PERIOD*10;

    -- First write to testRAM
    wait for CLK_PERIOD*100;
    A_ADDR  <= "00000010000000";
    B_ADDR  <= "00000011000000";
    A_DIN   <= "000000000010000000";
    B_DIN   <= "000000000011000000";
    A_WEN   <= "11";
    B_WEN   <= "11";
    wait for CLK_PERIOD;

    --Change from wr to rd
    A_WEN <= "00";
    B_WEN <= "00";
    wait for 100 us;          --maybe wait a long time?

    -- Second write to testRAM
    A_ADDR  <= "00000100000000";
    B_ADDR  <= "00000100000000";
    A_DIN   <= "000000000100000000";
    B_DIN   <= "000000000100000000";
    A_WEN   <= "11";
    B_WEN   <= "11";
    wait for CLK_PERIOD;

    -- Change from wr to rd
    A_WEN   <= "00";
    B_WEN   <= "00";
    wait for 100 us;          --maybe wait a long time?

    --Rd from first address set
    A_ADDR  <= "00000010000000";
    B_ADDR  <= "00000011000000";
    wait for 100 us;          --maybe wait a long time?

Generated Entity from SmartDesign:

----------------------------------------------------------------------
-- Created by SmartDesign Wed Jul 19 12:24:41 2023
-- Version: 2023.1 2023.1.0.6
----------------------------------------------------------------------

----------------------------------------------------------------------
-- Libraries
----------------------------------------------------------------------
library ieee;
use ieee.std_logic_1164.all;

library smartfusion2;
use smartfusion2.all;
----------------------------------------------------------------------
-- sd_ram1k18 entity declaration
----------------------------------------------------------------------
entity sd_ram1k18 is
    -- Port list
    port(
        -- Inputs
        A_ADDR        : in  std_logic_vector(13 downto 0);
        A_ARST_N      : in  std_logic;
        A_BLK         : in  std_logic_vector(2 downto 0);
        A_CLK         : in  std_logic;
        A_DIN         : in  std_logic_vector(17 downto 0);
        A_DOUT_ARST_N : in  std_logic;
        A_DOUT_CLK    : in  std_logic;
        A_DOUT_EN     : in  std_logic;
        A_DOUT_LAT    : in  std_logic;
        A_DOUT_SRST_N : in  std_logic;
        A_EN          : in  std_logic;
        A_WEN         : in  std_logic_vector(1 downto 0);
        A_WIDTH       : in  std_logic_vector(2 downto 0);
        A_WMODE       : in  std_logic;
        B_ADDR        : in  std_logic_vector(13 downto 0);
        B_ARST_N      : in  std_logic;
        B_BLK         : in  std_logic_vector(2 downto 0);
        B_CLK         : in  std_logic;
        B_DIN         : in  std_logic_vector(17 downto 0);
        B_DOUT_ARST_N : in  std_logic;
        B_DOUT_CLK    : in  std_logic;
        B_DOUT_EN     : in  std_logic;
        B_DOUT_LAT    : in  std_logic;
        B_DOUT_SRST_N : in  std_logic;
        B_EN          : in  std_logic;
        B_WEN         : in  std_logic_vector(1 downto 0);
        B_WIDTH       : in  std_logic_vector(2 downto 0);
        B_WMODE       : in  std_logic;
        SII_LOCK      : in  std_logic;
        -- Outputs
        A_DOUT        : out std_logic_vector(17 downto 0);
        BUSY          : out std_logic;
        B_DOUT        : out std_logic_vector(17 downto 0)
        );
end sd_ram1k18;
----------------------------------------------------------------------
-- sd_ram1k18 architecture body
----------------------------------------------------------------------
architecture RTL of sd_ram1k18 is
----------------------------------------------------------------------
-- Component declarations
----------------------------------------------------------------------
-- RAM1K18
component RAM1K18
    generic(
        MEMORYFILE : string := "" ;
        RAMINDEX   : string := ""
        );
    -- Port list
    port(
        -- Inputs
        A_ADDR        : in  std_logic_vector(13 downto 0);
        A_ARST_N      : in  std_logic;
        A_BLK         : in  std_logic_vector(2 downto 0);
        A_CLK         : in  std_logic;
        A_DIN         : in  std_logic_vector(17 downto 0);
        A_DOUT_ARST_N : in  std_logic;
        A_DOUT_CLK    : in  std_logic;
        A_DOUT_EN     : in  std_logic;
        A_DOUT_LAT    : in  std_logic;
        A_DOUT_SRST_N : in  std_logic;
        A_EN          : in  std_logic;
        A_WEN         : in  std_logic_vector(1 downto 0);
        A_WIDTH       : in  std_logic_vector(2 downto 0);
        A_WMODE       : in  std_logic;
        B_ADDR        : in  std_logic_vector(13 downto 0);
        B_ARST_N      : in  std_logic;
        B_BLK         : in  std_logic_vector(2 downto 0);
        B_CLK         : in  std_logic;
        B_DIN         : in  std_logic_vector(17 downto 0);
        B_DOUT_ARST_N : in  std_logic;
        B_DOUT_CLK    : in  std_logic;
        B_DOUT_EN     : in  std_logic;
        B_DOUT_LAT    : in  std_logic;
        B_DOUT_SRST_N : in  std_logic;
        B_EN          : in  std_logic;
        B_WEN         : in  std_logic_vector(1 downto 0);
        B_WIDTH       : in  std_logic_vector(2 downto 0);
        B_WMODE       : in  std_logic;
        SII_LOCK      : in  std_logic;
        -- Outputs
        A_DOUT        : out std_logic_vector(17 downto 0);
        BUSY          : out std_logic;
        B_DOUT        : out std_logic_vector(17 downto 0)
        );
end component;
----------------------------------------------------------------------
-- Signal declarations
----------------------------------------------------------------------
signal A_DOUT_net_0 : std_logic_vector(17 downto 0);
signal B_DOUT_net_0 : std_logic_vector(17 downto 0);
signal BUSY_net_0   : std_logic;
signal A_DOUT_net_1 : std_logic_vector(17 downto 0);
signal B_DOUT_net_1 : std_logic_vector(17 downto 0);
signal BUSY_net_1   : std_logic;

begin
----------------------------------------------------------------------
-- Top level output port assignments
----------------------------------------------------------------------
 A_DOUT_net_1        <= A_DOUT_net_0;
 A_DOUT(17 downto 0) <= A_DOUT_net_1;
 B_DOUT_net_1        <= B_DOUT_net_0;
 B_DOUT(17 downto 0) <= B_DOUT_net_1;
 BUSY_net_1          <= BUSY_net_0;
 BUSY                <= BUSY_net_1;
----------------------------------------------------------------------
-- Component instances
----------------------------------------------------------------------
-- RAM1K18_0
RAM1K18_0 : RAM1K18
    port map(
        -- Inputs
        A_CLK         => A_CLK,
        A_DOUT_CLK    => A_DOUT_CLK,
        A_ARST_N      => A_ARST_N,
        A_DOUT_EN     => A_DOUT_EN,
        A_BLK         => A_BLK,
        A_DOUT_ARST_N => A_DOUT_ARST_N,
        A_DOUT_SRST_N => A_DOUT_SRST_N,
        A_DIN         => A_DIN,
        A_ADDR        => A_ADDR,
        A_WEN         => A_WEN,
        B_CLK         => B_CLK,
        B_DOUT_CLK    => B_DOUT_CLK,
        B_ARST_N      => B_ARST_N,
        B_DOUT_EN     => B_DOUT_EN,
        B_BLK         => B_BLK,
        B_DOUT_ARST_N => B_DOUT_ARST_N,
        B_DOUT_SRST_N => B_DOUT_SRST_N,
        B_DIN         => B_DIN,
        B_ADDR        => B_ADDR,
        B_WEN         => B_WEN,
        A_EN          => A_EN,
        A_DOUT_LAT    => A_DOUT_LAT,
        A_WIDTH       => A_WIDTH,
        A_WMODE       => A_WMODE,
        B_EN          => B_EN,
        B_DOUT_LAT    => B_DOUT_LAT,
        B_WIDTH       => B_WIDTH,
        B_WMODE       => B_WMODE,
        SII_LOCK      => SII_LOCK,
        -- Outputs
        A_DOUT        => A_DOUT_net_0,
        B_DOUT        => B_DOUT_net_0,
        BUSY          => BUSY_net_0
        );

end RTL;

Zoomed in waveform (initial values & and setting A_WEN to "11" (write en)):

Zoomed out waveform showing no change in busy signal:

I have been using this doc (pages 54 - 61) for reference: https://www.microsemi.com/document-portal/doc_view/130906-smartfusion2-and-igloo2-macro-library-guide

I look forward to your responses and appreciate the help.

You've put in a bit of your test bench, but where is your code which does the work? VHDL or Verilog? (Or something else?) — Puffafish, Aug 07 '23 at 15:21
VHDL. I am using Libero SmartDesign which is a visual block-based design creation and entry tool for the instantiation, configuration, and connection of Microchip IPs. I'll append the generated code for the 1K18 entity. — gdagis97, Aug 07 '23 at 15:34
