CircuitMaker is generating outlines for internal resistors and I think the manufacture will cut holes in those places.

The PCB view (top layer) is: enter image description here

The problems are resistors R4, R5, and R1.

The outline is below:

enter image description here

See the red cicles that mark the resistors. Why is that outline generated?

Finally, I have used ViewMate to verify the outline Gerber file:

enter image description here

As you can see, the three resistors are outlined. Does this mean the manufacturer will make holes in those 3 rectangles?

I have tried to select these rectangles and delete them, but I cannot select them. I certainly haven't added them myself.

What can I do?

Martel
  • 1,213
  • 6
  • 20
  • Depends on the PCB-Service you will use. Of course, best would be to remove the outline of the resistors. But: If you write a comment/email to your service, they will be happy to just not route them. – ElectronicsStudent Aug 06 '23 at 11:28
  • 1
    maybe the hole is to allow the resistor to have a lower profile when assembled onto the board – jsotola Aug 06 '23 at 17:25

1 Answers1

1

I solved it by changing to a different resistor with a similar footprint.
