Right now I try to reverse engineer a piece of electronic which consists of 3-phase (BLDC) motor driver and a microcontroller with FOC running on it. My goal is to replace that piece of firmware with my own. Until now I have a good part of the schematic drawn but have some quiestionmarks still.

One of those is: where the heck is the bootstrapping diode connected to? Usually it has to be connected to the drain. Are there any other possibilities? I know this is a broad question but still. Maybe there is a bootstrapping technique I haven't seen yet.

enter image description here

stowoda
  • 530
  • 5
  • 12
  • Probably +5V if the low side runs off it. Seems suspiciously low though. – winny Aug 01 '23 at 11:54
  • Yeah, one would like to squeeze the most (or less) of the Rds_on usually. – stowoda Aug 01 '23 at 11:56
  • 2
    @winny Considering you lose 0.7V in the emitter follower, then another 0.4V or whatever in the diode, also minus whatever Vds of the low side driver is when driving the motor, also minus the drop across R124.. seems low especially since that MOSFET is not specified below 4.5V. – Spehro Pefhany Aug 01 '23 at 12:11
  • @winny I'm agreeing with you and enumerating why. – Spehro Pefhany Aug 01 '23 at 12:41
  • 1
    If you have access to +12 or +15, I don't see any reason to not tie both drivers to that rail instead. – winny Aug 01 '23 at 12:44
  • @winny, yeah thought about that as well but not before I know what else is connected to that net (I'd like to avoid a short). – stowoda Aug 01 '23 at 12:54
  • If you are making a new board based of this design, you should have the freedom to split it. The 2N7002 will “isolate” your logic level gate input to whatever pull-up it has on source. Was the original design based on some very low Vgsth MOSFET per chance? – winny Aug 01 '23 at 12:59

2 Answers2

5

It's typically connected to a ground-referenced power supply of 10V or whatever so that when the low-side driver turns on the source of the high-side transistor is grounded and the bootstrap capacitor charges.

That supply is missing from your schematic.

Spehro Pefhany
  • 376,485
  • 21
  • 320
  • 842
  • 1
    Or considering the low side is run at 5V, it could be that as well. (Which would be suitable for a FDMC8032L logic-level dual FET.) – Tim Williams Aug 01 '23 at 11:34
  • @TimWilliams, I have considered that as well but can not measure "continuity" with a DMM between the diode's cathode and that 5V supply. – stowoda Aug 01 '23 at 11:49
  • @Spehro Pefhany, yeah, a Voltage source which adds on top to the source voltage so it is well above the mosfet's gate-source threshold voltage. I have thought about that as well but was not able to figure out that connection on the PCB yet. Maybe, considering that it is a battery powered device, it gets turned on at some point by firmware.. But that seems strange to me (power saving reasons.. ?!). – stowoda Aug 01 '23 at 11:53
  • @stowoda Hmm, could be? That 2.2k pullup won't exactly be sipping microamperes if it were hard-wired. I'd rather a CMOS driver myself; but that might well do the job, if a bit unorthodox. – Tim Williams Aug 01 '23 at 13:35
  • @TimWilliams They can drive the outputs low though, which only leaves the 47k resistors. They're emitter followers so the base current will be negligible in comparison. – Spehro Pefhany Aug 01 '23 at 13:39
  • @SpehroPefhany To be clear, the low-power state (at least, given what's here, and assuming +5V is always-on) would be: low-side outputs on (gates pulled up to +5), high-side outputs off (gates pulled down to 0V by drivers, bootstrap power disabled). The pull-up/down resistors (from 3.3/0) on the 2N7002s seems to support this. The low-side 47k pulldown would seem to be erroneous (perhaps a force of habit?), in that case! – Tim Williams Aug 01 '23 at 13:42
2

Allright, I have found it. Thanks for all your suggestions.

The MCU turns T33 on through T32. So indeed +5V is the Voltage we were looking for. Regarding the comments about the relatively low V_gs_th: the power transistor is an FDMC8030 and not xx8232 as stated before, which has a lower threshold voltage:
