Is there something like this connector that is easier to buy? I need to find something that lets me connect an aluminium PCB to an FR4 PCB with part of the enclosure between them. The part of this connector that sticks into the PCB is spaced from the SMD legs enough to not have to worry about shorting any of the pins on the aluminium core. https://www.ghgmlink.com/g15-m2012-double-row-right-angle-dip-led-light-connector-straight-style-intelligent-lighting-connector-pitch-2-0mm-2-6-pin-female-mating-connector_p42.html

Connectors like this a commonly found in downlights and allow you to pass pins through the connector on each PCB.

enter image description here

Image Source: Photos I took myself.

Dan
  • 133
  • 8

1 Answers1

0

For example Samtec BCS is a pass-through pin socket: https://www.samtec.com/products/bcs

The pin header just needs to be long enough to extend far enough to the other side of the PCB.

Ralph
  • 3,026
  • 1
  • 4
  • 22
  • Thanks Ralph. Through hole connectors like that are very difficult to use with aluminium PCBs. And although Samtech and other brands have SMD equivalents, the aluminium wouldn't be "spaced from the SMD legs enough to not have to worry about shorting any of the pins to the aluminium core." – Dan Jul 08 '23 at 12:42
  • If it's just a protective element, could you use for example a panel mounted LED holder? – Ralph Jul 08 '23 at 13:06
  • > I'm asking if there is something similar that's easier to purchase, hoping for a vendor like DigiKey or Mouser. -- No, there aren't. These particular ones are only made and sold by Chinese sources. – Davide Andrea Jul 08 '23 at 15:57
  • Thanks Ralph. I think you could do that for a larger pitch and with long enough legs to bend back to a pad. Might be difficulty with a connector like this though. Maybe a 2L adaptor PCB could add the clearance I'm after to the connector you suggested. – Dan Jul 09 '23 at 06:15
