I have an LCD hooked up to the A ports of a PIC16F877a (A0, A1, A2 etc). However, the display doesn't work because PORTA is configured as analog by default.

In an PIC18F46K22 I'd do it using ANSELA = 0x00; but there is no such option in the PIC16F877A. I looked everywhere on the internet and some solutions suggested turning off the ADCON1 and bits, but nothing, ABSOLUTELY nothing works.

I changed the connection pins to PORTD (D0, D1, D2 etc) and it worked just fine. The problem is the analog configuration of PORTA which I can't change no matter what I try.

I am using MikroC for the program and here's my code:

sbit LCD_RS at RA0_bit;
sbit LCD_EN at RA1_bit;
sbit LCD_D4 at RA2_bit;
sbit LCD_D5 at RA3_bit;
sbit LCD_D6 at RA4_bit;
sbit LCD_D7 at RA5_bit;

// Pin direction
sbit LCD_RS_Direction at TRISA0_bit;
sbit LCD_EN_Direction at TRISA1_bit;
sbit LCD_D4_Direction at TRISA2_bit;
sbit LCD_D5_Direction at TRISA3_bit;
sbit LCD_D6_Direction at TRISA4_bit;
sbit LCD_D7_Direction at TRISA5_bit;

void main()
{

     ADCON1 = 0x00;
     ADCON0 = 0x00;
     TRISA = 0x00;
    Lcd_Init();
    while (1)
    {
      Lcd_Out(1,1,"Hello");
      Lcd_Out(2,1,"World");
    }
}

This site is my last hope, I don't even know if there's another human who uses this microcontroller in 2023 :D

EDIT: ANSELH doesn't exist either. Even ChatGPT fails to solve this issue.

1 Answers1

4

You are setting ADCON1 incorrectly. Have a look in the example assembly code for PORTA initialisation in the datasheet:

ADCON1 initialisation

This corresponds to 0b0000_0110 being written to the ADCON1 register. Cross referencing that with register description in REGISTER 11-2:

PCFG[3:0]

shows this is the value required to set all of PORTA to digital.

Beyond that, pin RA4 is not a push-pull output - it is an open drain output (note the schematic is wrong, the output from the registers is actually !Q not Q):

RA4 schematic view

This means it can only pull the output to ground. You might be able to solve the problem by putting a pull up resistor from RA4 to VCC.

awjlogan
  • 7,879
  • 2
  • 29
  • 45
  • 1
    Thanks for the response, I did look at that part of the datasheet and updated my code accordingly. It still doesn't work as expected. I went the extra mile and disabled other multiplexed functions still to no avail. I guess It's time to look into "project settings" and all. Thanks again. – HeavyPendulum Jul 05 '23 at 14:37
  • Odd - have you tried writing `0x00` to `PORTA` to initialise it as well as shown in the assembly example (`CLRF PORTA`)? Bit 5 is `x` at reset, which might affect the LCD init routine. Might be worth disconnecting the LCD and just trying to get some LEDs blinking! – awjlogan Jul 05 '23 at 14:46
  • Yep, I did that as well, still didnt' work. At this point it's worth mentioning that after reconnecting the pins to PORTD everything once again works fine. – HeavyPendulum Jul 05 '23 at 14:50
  • Ah - there's the problem - `RA4` is an open drain output, not a push pull. It won't drive the `LCD_D6` pin correctly. I'll edit the answer to reflect that... – awjlogan Jul 05 '23 at 14:59
  • 1
    That solves the issue. I'm kind of glad the solution was something I couldn't have come up with since I'm only a sophomore-year intern and I thank you for your answer. – HeavyPendulum Jul 05 '23 at 15:13
  • You're welcome - enjoy the rest of the project! – awjlogan Jul 05 '23 at 15:13
