Capacitor marking with line underneath; these aren't tantalum (I don't think anyway), so I'm not sure which units the capacitance is written in.

Capacitor marking with line underneath

Velvel
  • 3,591
  • 3
  • 12
  • 30
Shashvat Verma
  • 83
  • 5
  • 2
    How come you only considered options `pF` and `µF`? What about `nF` (which lies inbetween magnitude wise)? – MEMark Jul 01 '23 at 07:31
  • 2
    @MEMark From what I've heard, the capacitance of a capacitor is often described in terms of pF or µF, but rarely in terms of nF. – Cassie Swett Jul 02 '23 at 04:20

3 Answers3

10

That is a ceramic disc capacitor, 47 pF.

Here's a datasheet for a typical capacitor of this type: enter image description here
https://www.vishay.com/docs/28515/sseries.pdf

A good clue: The two capacitors, crystal, and resistor appear to be an oscillator circuit, perhaps for the IC next to them; in this use the capacitors are almost always a few 10s of pF.

This circuit is from ST's excellent oscillator design guide for these AN 2867 enter image description here

jonathanjo
  • 12,049
  • 3
  • 27
  • 60
  • 1
    Thanks to everyone who commented! Yes, good eye. It's in a Pierce Oscillator, and the IC is a hex inverter. The hand-drawn circuit sketch I received mislabelled it as microF, and I am very pleased that this might be what could fix my issue! – Shashvat Verma Jun 30 '23 at 12:36
  • To check, will having a much larger sets of capacitors connected to this circuit, potentially cause damage to the components? – Shashvat Verma Jun 30 '23 at 12:39
  • 1
    Generally it's good to keep question separate: can I suggest you post a new question with a diagram of what you're asking? – jonathanjo Jun 30 '23 at 12:41
  • 1
    @ShashvatVerma Larger capacitance values should not damage anything, however the circuit will likely not oscillate. Check electrical description of Pierce oscillator. The capacitors & crystal form a tank circuit that needs a certain balance of values. – pwrgreg007 Jul 02 '23 at 16:59
8

Encoding for Ceramic Capacitors

Ceramic capacitors encoding consists 1-3 digits.

If the capacitor code consist only 1 or 2 digits, it is simply their capacitance value in PicoFarads (pF). For example if a ceramic capacitor has a code ‘5’ and other has ‘47’, their respective capacitance values are 5 pF and 47 pF.

Source: https://circuitdigest.com/calculators/capacitor-value-code-calculator

Velvel
  • 3,591
  • 3
  • 12
  • 30
7

That is a ceramic disc capacitor, normally you would have three figures on it, and the value is in pF; 470 means 47 x 10^0 = 47 pF, 102 = 10 x 10^2 = 100 pF and so on.

I suppose in this case they just omitted the 0 for some reason.

Rest assured it is not a 47 µF capacitor
