Software engineer here :) Never work with electronics before and now my air conditioner is not working and I decided to check it myself.

This is a PCB from old air conditioner. And when the power is on, the relay RY02 switched on for a split second and tuned off again. Should be ON all time so the fan will work.

Explanation of photo:

  1. Red line is a signal to turn on the fan.
  2. Orange line is a signal to turn ac compressor.
  3. Blue - probably 12 V load for relays RY02 and RY03.
  4. RY01 - is a main power relay with 220 V.
  5. Yellow lines are lines to the ac compressor and fan accordingly to the relays.
  6. RY02 - relay for FAN.
  7. RY03 - relay for AC Compressor.
  8. D02 - diode (W6)

I don't understand why there is a diode D02 in RY02 relay? What is its purpose? And why there is no diode on second relay RY03?
