I'm checking the default configuration of an ethernet communication project based on STM32F2 microcontroller (stm32f207 RM0033 UM). Where the comments I'm gone to do, they could be find on section 28.6.2 (page 881, etc). I think it doesn't mind but my ethernet application is using HAL driver layer, LwIP and no RTOS.

I'm also reading the datasheet looking for information about peripheral registers values and their meaning. Specially those who deal with transmission and reception DMA buffers, descriptors, FIFO buffers, etc. But I don't understand some assertion it does, because the same assertion seems to has the opposite one on another part of the same datasheet regarding the same functionality/configuration. I was on the DMA host burst access section.

"The DMA attempts to execute fixed-length burst transfers on the AHB master interface. The maximum burst length is indicated and limited by the PBL field. The receive and transmit descriptors are always accessed in the maximum possible burst size (limited by PBL) for the 16 bytes to be read."

But then says:

"When the AHB interface is configured for fixed-length burst, then it transfers data using the best combination of INCR4, INCR8, INCR16 and SINGLE transactions."

I though they were firstly talking about fixed-length programming on the corresponding register, not a mix of burst length sizes.

"When the AHB interface is configured for address-aligned beats, the DMA can only align the address for beats up to size 16 (for PBL > 16), because the AHB interface does not support more than INCR16."

Looking at this register description:

"These bits indicate the maximum number of beats to be transferred in one DMA transaction."

Here, I don't know if beats means number of data units or bursts of a number of data units. Where data units are: byte, half-word or word.

PBL and RDP are fields from ETH_DMABMR register (configuration register), and data sheets says:

"PBL can be programmed with permissible values of 1, 2, 4, 8, 16, and 32. Any other value results in undefined behavior.

  • The maximum number of beats (PBL) possible is limited by the size of FIFO
  • The FIFO has a constraint that the maximum beat supported is half the depth of the FIFO
  • Do not program out-of-range PBL values, because the system may not behave properly."

RDP is a field that is the equivalent to PBL but only applies to RX DMA transfers. Datasheet also says:

"RDP = RxDMA PBL:

  • These bits indicate the maximum number of beats to be transferred in one RxDMA transaction.
  • The RxDMA always attempts to burst as specified in RDP.
  • Permissible values of 1, 2, 4, 8, 16, and 32. "

I'm confused for these datasheet assertions shown before:

  • Permissible values of 1, 2, 4, 8, 16, and 32.
  • the DMA can only align the address for beats up to size 16.. AHB interface does not support more than INCR16.
  • The receive and transmit descriptors are always accessed in *the maximum possible burst size (limited by PBL) for the 16 bytes to be read

So now, and having this other found DMA information in mind (dma controller AN4031 - 12 and 13 pages):

picture from AN4031 for stm32f2 dma controller

My doubts are:

  1. When talking about INCx, where should this INCx be put? What is an INCx? Is it a burst length?

  2. What is the legal max value of burst that can be programmed and how is it chosen?

  3. If my project is using a default configuration that has RDP options for programing the burst size and its value is set to 32. What does exactly this 32 mean regarding to the burst size? 32 bursts of what? Is it a burst of 32 data unit? beats of 32 bursts? bursts of 32 beats? burst of 32 bytes? Burst of 32 bits?

  4. What about the max data length to be read 16 byte-sized? If this field is 32:

  • 1 byte --> 32x1 byte = 32 bytes > 16 bytes,
  • 2 bytes --> if 32x2 bytes > 16 bytes and
  • 4 bytes --> 32x4 bytes = 128 bytes > 16 bytes.
  1. What about PBL/RDP value (32) and the FIFO size (2 kB)? Which relationship is between these two values?

Please if some one could briefly making a comprehensive and better explanation I will be very grateful. Should I write a PBL value less than "32"?

winny
  • 13,064
  • 6
  • 46
  • 63
Suvi_Eu
  • 777
  • 6
  • 19
  • You can choose to limit the number of transfers the dma does in one go - burst. This is usually done so that the dma doesn’t potentially hinder access by the cpu by hogging the bus. There are other reasons as well. What does the HAL driver do? It will most likely configure exactly what is required and no intervention is required by you. – Kartman Jun 15 '23 at 22:49
  • I knew that the number is regarding to number of transfers. But I need to clarify questions I have done. Why they say max value is 16 but later they said it is 32? HAL usally has reported more bugs than is desirable. I need to know if 32 is correct for me. But there seems to be limitations: 16 bytes, FIFO, etc.. but is not explained in which maner. Or maybe I didn't understand the datasheet literature correctly. So, due to this fact, there are my 5 questions. Thanks for your attention. – Suvi_Eu Jun 16 '23 at 06:20
  • 1
    Your link is to the datasheet but you reference the user/reference manual. What do you want us to look at? Table 3 has no mention of a 32 byte transfer. You should ask ST for clarification as if there is a mistake in their documentation, then we can’t fix it. – Kartman Jun 16 '23 at 12:40
  • @Kartman thank you for the observation. It was a mistake. I've edited this and both references are correct now. I tried to did what you said but unfortunately ST costumer service and its community platform too, both were suspended for several days due ST platform migration settings. It seems to be active this week. I wil try once again. But if someone knows what I'm asking and someone sees wrong assertions on my post, please let me know. – Suvi_Eu Jun 19 '23 at 08:01
