I'm using QucsStudio4.3.1 to simulate a voltage divider circuit. Everything is fine until I try to plot the result.

The tutorial shown like below

Result shown from tutorial

enter image description here

But the result I got is like

enter image description here

Missing a properties from a "battery"(V1.I)

Even I tried to manually type it in the blank of "Graph Properties", it just shown "Unknown variable 'V1.I'."

enter image description here

Below is my circuit and tutorial's

My circuit

Tutorial's circuit

I have followed the rules of available dataset items

enter image description here

Could someone point out where the problem is?

*Reference - A Tutorial Getting Started with Qucs Page 12

Greenonline
  • 2,064
  • 7
  • 23
  • 38
Jack Huang
  • 53
  • 5

1 Answers1

4

The tutorial uses Qucs and not Qucsstudio.

In Qucsstudio you must add an current probe to make this measurement.

screan simulation
