10-contact FPC socket has 12 PCB terminals

Question

I have to place an FPC socket on my PCB. I selected 0.5 pitch and 10 contacts connector. Everyone has 12 PCB terminals instead of 10.

I am confused, what are those two extra pins for?

Davide Andrea · Accepted Answer · 2023-05-04T16:15:46.157

7

To hold the connector in place. They are "anchors", though various companies call them with different names.

edited May 04 '23 at 16:15

answered May 04 '23 at 16:08

Davide Andrea

Thanks a lot for the answer, so i don't have to wire them in my design? – Mukund May 04 '23 at 16:13
1

No, you don't. They are just pads. – Davide Andrea May 04 '23 at 16:16
thank you very much – Mukund May 04 '23 at 16:17
Don't forget to do your part: voting and accepting. – Davide Andrea May 04 '23 at 16:31
2

To be clear to the OP about connecting them in the schematic: there is really nothing to connect. There is no electrical connection from extra pads to the FPC; they exist only to provide a solid mechanical connection to the PCB. – spuck May 04 '23 at 22:34
4

Connecting them to groundplane with vias can increase the strength of the pad to prevent it from being lifted off the PCB. – jpa May 05 '23 at 08:05
