Is there any way to get a 5V TTL signal (pulse of whatever duration, could even be a boxcar) from a button press with a very simple circuit or with some consumer device?

I need this to do some debugging, and am a bit surprised — given how ubiquitous TTL pulses are in electronics — that I can't find anything for the simplest possible instantiation of creating such a pulse. I would imagine a lot of people need such a device just to test stuff out I have found a number of questions here (e.g. this one), but they seem to address much more specific use cases.

I guess I could just connect a few batteries in series to get to about 5V and just connect/disconnect the wires... But that would give me a lot of current as well, in addition to being pretty finicky to operate.

TheChymera
  • 123
  • 3
  • Yes? A button already does this. If you connect it to 5V and a pull-down resistor, or vice versa. – user253751 Apr 24 '23 at 18:32
  • 1
    well, for TTL you presumably want it connected to ground with a pull-up, because TTL likes to sink current into outputs and not source it. If you just want a 5V pulse, then either way works. – user253751 Apr 24 '23 at 18:32
  • What is "a boxcar"? – jonathanjo Apr 24 '23 at 18:43
  • If looking for a consumer device, I'd probably guess that Adafruit would be the place to look. (No idea if they sell it, but I associate them as trafficking in these kinds of products since it fits their customer base well, to my mind.) They do have [a blog](https://blog.adafruit.com/2020/04/22/ultimate-guide-to-switch-debounce-eejournaltfm-maxmaxfield/) on the topic. I used to use the 74121 and/or 74123, but those may be getting scarce. Have you looked at the 74123? – periblepsis Apr 24 '23 at 22:52

2 Answers2

1

Make a simple pulser with a microswitch and a flip flop to create a debounced TTL signal. Usually you can make something like this out of found parts. You'll need some clips and/or a probe to connect to the power of the circuit under test and inject the signal. enter image description here

Image source: https://www.eejournal.com/article/ultimate-guide-to-switch-debounce-part-5/

D Duck
  • 2,041
  • 1
  • 8
  • 18
0

Many people use the GPIO pins of their computer for this; if not available, then handshake lines of a USB TTL serial port might work for you.

There are a great number of such things available: enter image description here
Google search for usb ttl serial port

jonathanjo
  • 12,049
  • 3
  • 27
