I am currently trying to make my own development board but have run into a bit of a pickle. I want to be able to Auto Program the ESP32 since pressing a button each time is not something that I would like to do. I do know how to make an Auto Program circuit but I am not sure how I would wire it up to this converter since it is my first time using it! :-D

TLDR: Is there a way to make an Auto Program circuit with the MCP2221A and ESP32-S3 and still keep the GP0 and GP1 pins to indicate RX & TX traffic? (The input voltage is 5V and I will be using an isolator for stepping down to 3.3V for the ESP32 module. If this is relevant)

enter image description here

This is the current schematic of the MCP2221A that I have drawn.

enter image description here

And this is the ESP32 module.

Ask
  • 11
  • 3
  • 2
    Maybe you can explain what an *Auto Program circuit* is or does? – Andy aka Jan 22 '23 at 17:32
  • If *Auto Program circuit* refers to the circuit for resetting the ESP and putting it into bootloader mode via a serial connection, then the MCP2221A won't work. That circuit uses the DTR and RTS signals, which are not available on the MCP2221A. You could emulate them using GPIOs; but then you will likely need to create a replacement for *esptool*. – Codo Jan 22 '23 at 19:56
  • Why are you add a USB-to-serial chip anyway? Is the built-in USB-to-UART bridge not sufficient? – Codo Jan 22 '23 at 19:57
  • @Codo Oh, ok. Thought it could do that. Guess I will take a look at the CH340C chip then. Or maybe the MCP2200 since it has RTS and CTS pinouts? – Ask Jan 22 '23 at 22:07
  • @Codo I am not sure that the ESP32 has built in USB-to-UART? Cannot see it anywhere in the datasheets? – Ask Jan 22 '23 at 22:10
  • See https://www.espressif.com/sites/default/files/documentation/esp32-s3_datasheet_en.pdf, ch "3.5.12 USB Serial/JTAG Controller". It does not apply to the original ESP32. – Codo Jan 23 '23 at 08:20
