I was checking a drawing datasheet, and I noticed this symbol. A B inside a triangle. As seen on the screenshot, the symbol is on the side of the table that indicates the pinout.

I can't find out anywhere what it means. Any help?

enter image description here

Found this info at the bottom of the drawing datasheet

enter image description here

NicoCaldo
  • 305
  • 4
  • 12

1 Answers1

13

Without any triangle it'll be a general note.

With triangle it'll be an indication for revision. In your question, the B-in-triangle is placed quite close to the row-2 of the table. It indicates that there is a revision in the row-2, and the explanation shows that the content is changed from "PLUG NO - 3" to "MOLEX NO - 3".
