I have two 12 VDC actuators connected to a 4-position joystick. I need to be able to control the speed of one actuator only; the other will run at full speed.

Could you draw and/or explain how I could to wire a 12 VDC speed controller into this circuit? If I put in the motor-out contacts it doesn't work because the power polarities change when the joystick is in a reverse position.

Maybe I have to run two complete circuits, but how do I wire the joystick controller?

enter image description here

ocrdu
  • 8,705
  • 21
  • 30
  • 42
Richard Sutton
  • 1
  • 2
  • What is your joystick? How does it work on the inside? What is the meaning of T/B/R/L pins? All we can say from the picture is that it's some kind of 'magic box' wit 8 pins – floppydisk Dec 17 '22 at 09:05
  • What are the boxes near the motors? Are they relays? In current configuration shown on the picture it looks like they are in short-circuit position when the motors are off. – floppydisk Dec 17 '22 at 09:10
  • Hi the boxes are relays . the t/b/ etc relate to the Top set of switches or the Bottom set – Richard Sutton Dec 18 '22 at 20:53
  • see the page from where i did the setup – Richard Sutton Dec 18 '22 at 20:53
  • dont know how to paste a pic so heres the link https://www.instructables.com/Rocker-Switch-and-Joystick-Wiring-w-Linear-Actuato/ – Richard Sutton Dec 18 '22 at 21:03

0 Answers0
