I want to drive these MOSFETs which will be in the cell-balancing circuit that is part of the BMS. What kind of topology for gate drivers can be suitable for this system?

enter image description here

JYelton
  • 32,302
  • 33
  • 134
  • 249
Shamurov
  • 143
  • 6

1 Answers1

1

3 highside and 1 lowside will do the job .You have lots of chips to choose from .Most chips have enough peak gate current for your application.The L1/C1 resonance eases up the switching requirements.This converter topology is becoming more popular so you may find a suitable quad chip.
