SR flip-flop with Preset and Clear should not work as described

Question

In the presented flip-flop, suppose the Enable signal is high, the S is low, and R is high. Now we set the Preset low (0) and the Clear high (1). In this condition, we expect Q=1 and Q'=0.

But checking the circuit gives us contradictory outputs. Because the Preset is low, the output of the upper NAND gate would be 1 and therefore Q=1. Since the R is high, the R* would be low (0) and therefore the output of the downside NAND gate would be also 1 or we can say Q^=1. That means both Q and Q' need to be high which is not possible.

What do you mean by "should not work" this way? It works how it works; if it doesn't work the way you want it to work then change the design. — Elliot Alderson, Oct 04 '22 at 19:19
Q and Q' being high at the same time is possible. It's just not allowed if you want to use it as a flip-flop. — StainlessSteelRat, Oct 04 '22 at 20:39

score 1 · Answer 1 · answered Oct 04 '22 at 20:28

1

By holding both the /Preset input Low and R input High you are forcing the flip-flop into an unstable (illegal) state.

When you change either of those inputs, the flip-flop will change to a legal state.

answered Oct 04 '22 at 20:28

Peter Bennett

57,014
1
48
127

score 0 · Answer 2 · answered Oct 04 '22 at 19:33

It means both Q and Q-complement need to be high which is not possible.

This is not a good point of view and analysis.
For analyzing this circuit, one should say first ... that the 2 outputs are labelled Q1 and Q2 ... and that if some conditions are met, Q1 & Q2 could be complementary states.

One must do a "complete" analysis before saying there is a "problem".
Note that for such analysis, it is very important to check all the delays associated with each gate, because behavior can be "different" ...

Check my post at this link for the R-S FF with NAND gates.
