I would like to solder Coto reed switch CT10-2540-G1 upside down into a slot. It would recede into the slot until the tips of the lead touched the pads.

enter image description here

enter image description here

Is there an IPC standard regarding the minimum pad coverage that would be required? I kept 0.3mm distance from the slot edge to the pad. I would like to make this smaller but my DRC flags anything less than 0.635mm and am hesitant to bring it any closer.

Null
  • 7,448
  • 17
  • 36
  • 48
Kaari_layout
  • 11
  • 1
  • 1
    This could work, but consider a drop of mild adhesive in the cut-out for support; the solder bond will likely be weaker. – rdtsc Jul 06 '22 at 19:57
  • Careful about using adhesive *on the brittle glass enclosure* -- it depends on flexible leads to avoid cracking due to thermal cycling. – DrMoishe Pippik Jul 06 '22 at 23:17
