I have TQ2-L2-3v DPDT relay that is getting activated by an ESP8266-12e pin. The problem is the pin doesn’t always output enough current to activate the relay so I want to wire a transistor (2n2222) to it. My question is since the only relays I have thus far connected to the 2N2222 have been non latching with the positive and ground interchangeable The TQ2-L2-3v has a designated + and - so I am not sure which way to wire it up.
I have made two schematics with the two different way I can think of the wiring.
Can someone tell me which way is the correct A or B, or are these two incorrect and what is the correct wiring?
Asked
Active
Viewed 71 times
2

user1114881
- 185
- 5
-
With D1 in the polarity you indicate, you're building a transistor blower-upper. You want the diode to be blocking when the transistor isn't conducting; it is there to conduct when the transistor turns _off_ and the coil needs a place for its current to go. – TimWescott Jun 10 '22 at 03:31
1 Answers
1
L2 designates a two coil latching relay, so you would need another transistor and GPIO pin.
The + pin will go to Vcc (it will be more positive when the transistor is conducting), but I'm not sure of your diagram- it appears to be rotated 180° for the markings to be readable, assuming it's the top view.
For future reference, please link to the datasheet PDF in your question text.

Spehro Pefhany
- 376,485
- 21
- 320
- 842
-
So let’s say I had the same set up on the other side. If VCC goes to + then B would be the correct set up, right – user1114881 Jun 10 '22 at 00:32
-
1
-
So the 1n4148 needs to be turned around to go from - to + in B and it should work. – user1114881 Jun 10 '22 at 01:19
-
-
