What is d in a boolean function?

Question

I know if it's \$ \Sigma \$ we put 1's in the Karnaugh map, but I don't know what \$ d \$ is.

$$ f(a,b,c,d) = \Sigma m(0,1,4,10,15) + d(7,14) $$

From what I've googled, https://en.wikipedia.org/wiki/Karnaugh_map it seems to be a "don't care", but I'm not so sure, because this is the first time I've seen this, and on the link and no where else can I see a \$ d() \$ reference.

You are correct. It is Don't Care! Kind of strange since d is also an input. — StainlessSteelRat, May 19 '22 at 16:51
I should use X in place of d. m is abbreviation for "minterm" ... — Antonio51, May 19 '22 at 16:53

score 5 · Accepted Answer · answered May 19 '22 at 16:53

5

Here is an example of d(...) being used for don't care conditions marked with an X: -

Image from Quora. Here's another example: -

Image from here.

answered May 19 '22 at 16:53
