I am trying to make a decoder that can display all alphabetical letters on a 7-segment display. My inputs are ABCDE and the outputs are abcdefg

truth table

Is this the correct truth table for a circuit? If yes, what would its transformation to normal form look like?

I think it is correct, but I am struggling to simplify it.

SamGibson
  • 17,231
  • 5
  • 37
  • 58
Elias Al Ahmar
  • 1
  • @JRE Beat me to it, again. – winny May 10 '22 at 10:47
  • 2
    If the right segments are driven, the truth table is correct. Checking this, though lengthy, is a trivial operation that you should be able to do yourself. As for solving, using a 5 variable K-map should be able to simplify it. You could also use the built-in functions of Logisim. – Bart May 10 '22 at 10:56
  • Use something like this (http://www.32x8.com/var5.html) for each segment. – devnull May 10 '22 at 11:23
