I have I2S MEMS microphones (transmitters, stereo) in slave mode and a microcontroller in master mode.

enter image description here

When the WS pin iw 0 (low) the data available on the SD pin is for the left channel (microphone 1.) When the WS pin is 1 (high) the data available on the SD pin is for the right channel (microphone 2.)

enter image description here

Is the data on the left and right channels synchronized or is the right channel data delayed by a few microseconds?

Would the delay depend on the sample rate. For example, for 16kHz sample rate, the right channel data is always delayed by 62.5µS?

JRE
  • 67,678
  • 8
  • 104
  • 179
CuriousByte
  • 11
  • 1

1 Answers1

0

The datasheet is not 100% clear on this, but based on the datasheet block diagram it would be a reasonable assumption that the samples are latched at the same WS edge, and the selection only defines when it is transmitted out.

Justme
  • 127,425
  • 3
  • 97
  • 261
  • Meaning both (Left and Right channel's) samples are taken at the same time but available to read one after another? – CuriousByte Apr 11 '22 at 10:13
  • Is there any reference code for this? I am not sure how data is packed when using both left and right channel. – Grabt234 Jan 19 '23 at 20:27
  • @Grabt234 Reference code for what? There is no software as this is a how data is transferred on a bus question and diagram in the question does describe how data is packed when using two channels. If you have a new question, ask a new question. – Justme Jan 19 '23 at 20:45
