simulate this circuit – Schematic created using CircuitLab

I built this circuit. Different versions of this exist on the internet, some using an MPF-102 JFET instead of the 3 NPNs. The various sites describe it in several different ways:

  1. "mains hum" detector
  2. static electricity detector
  3. "detects the presence of your hand without any physical contact"
  4. an "electronic electroscope"
  5. electromagnetic field detector
  6. EMF detector
  7. electrical noise detector
  8. "DC radar"
  9. "E-field detector"
  10. finally as a ghost, spirit, "aura" or "paranormal energy" detector!

The one I built behaves very strangely.

The LED lights if I hold the the circuit board and move the probe near a solid object. If I put the board on a table, it doesn't light as much, but it seems that any object with static electricity will light the LED if I rapidly move the object towards, away from, or back and forth near the probe.

A cotton towel does not light the LED and neither does any metal object, but my acrylic sweater does, and my hand will light it each time I scuff my feet on the nylon carpet.

It seems to light up especially bright when I jiggle a polypropylene plastic cup near it and will light when I either move the plastic cup quickly toward the probe, or hold it close to the probe then quickly move the plastic cup away.

If I hold the plastic cup still near the probe the LED goes out, then if I wiggle the plastic cup around the LED comes back on.

Despite what some of the web sites note, the LED does not light if I bring a plugged-in electric cord near the probe when the board is on a table.

Does anybody know what this actually "detects" and why it behaves as I've described?

JRE
  • 67,678
  • 8
  • 104
  • 179
Annette Gates
  • 669
  • 3
  • 10
  • If it behaves strangely then maybe it's the `ghost, spirit, "aura" or "paranormal energy"` that is causing you problems? – Andy aka Mar 07 '22 at 16:36
  • Also **radon detector** and **ion detector** if a DC electric field is added. All those you mention are related to *electric field*, except perhaps paranormal. **Triboelectricity** is often the source of static charge that influences the LED on/off state. – glen_geek Mar 07 '22 at 16:45
  • I built a similar circuit a long time ago and observed the same -- moving objects provoked a particularly strong response. – DamienD Mar 07 '22 at 20:01
  • http://amasci.com/emotor/chargdet.html – DamienD Mar 07 '22 at 20:07
  • https://web.archive.org/web/20121224163359/http://www.beam-wiki.org/wiki/Wilf_Rigter%27s_E-Field_Sensors – DamienD Mar 07 '22 at 20:07
  • Thanks for the links to the other websites. Very interesting and helpful. – Annette Gates Mar 07 '22 at 20:51
  • BTW, a true "darlington" would have collectors tied together, not having their own load resistors. – Theodore Mar 07 '22 at 21:09
  • I see that now. What would be the best description for this combination of NPNs and resistors instead of "darlington triplet"? Thanks! – Annette Gates Mar 08 '22 at 13:40
  • The load resistors are there because the emitter of Q1 needs to be tied to 0V, otherwise the stacked BE voltages will be too much to fit a LED drop with a ballast resistor as the emitter load for Q1. Instead, the transistors could be connected into a Sziklai Triplett. Only R1 would be needed then. – Kuba hasn't forgotten Monica Mar 12 '22 at 03:23

1 Answers1

4

Does anybody know what this actually "detects" and why it behaves as I've described?

You are basically detecting current on the base of the first 2N8050 (Q3), the rest of the transistors are to gain this current, if the current is high enough the LED will light. For objects that create 'static electricity' or static electric fields, The current comes through the air (air is considered an insulator, but can conduct really small currents through it usually less than nA but hard to say because conductivity air behaves differently because of humidity and the chemical makeup of it and that can vary from location to location). Lets say some object has 5000V of charge (which isn't hard to do) and humid air is around 100GΩ. there would be about 50nA of current flowing into a metal pin (like the pin of a 2N8050 transistor).

Many materials (especially plastics and paper and especially after rubbing against another material) can carry surface charges of thousands of volts. Clothing can also do this with varying results. The human body in combination with movement with clothing or the floor can also generate kV's of charge, even several kV from head to toe.

The pin can also function like an antenna and pick up RF (or if you have any other wires attached to the pin), these small currents are also gained up and lights the LED.

The problem is it would be hard to distinguish which source the circuit is picking up, because so many sources could activate the LED.
