I've loaded the crimp terminal two different ways in my crimper, but I haven't the experience to say which is correct.

Cursory web research doesn't seem to answer the question.

Edit: this is the first halves of butt connectors. The other halves aren't crimped yet. (The UI here wouldn't let me upload the whole photo.)

two crimped connectors, one on a black wire and one on a white wire

Mathieu K.
  • 287
  • 2
  • 9

1 Answers1

3

The one with the white cable. Remove the red plastic to see why. The copper is contacted in the middle, and there's a small tube that you simply have to squeeze. At the end however there's two flaps that need to be bent inside to stick on the cable insulation.
