Is this power supply universal input voltage?

Question

I have this Playstation 2 power supply which was originally run at 110V input. A fellow member of this forum suggested that there might be a good chance that it could a universal input voltage and might work at 220V AC.

I have taken a look at the power supply board and I couldn't figure whether this could be true. I'm posting the photo of my board and also the part numbers of components that I was able to identify. I know for sure that the fuse is for 110V but other components I'm not so sure. I tried searching for the transformer and inductor coil datasheets but none exists. They are of Matsushita make.

Please help me determine whether this power supply is having universal input voltage (aside from the fuse)

For such a power supply to be universal, not only does it need to support the higher voltage, but it also needs to output the same regulated voltage whether the input is 110 or 220… The fact they used a 110V fuse makes that quite unlikely IMHO. — jcaron, Aug 13 '21 at 14:44
@winny It's ok. I was originally planning to use my ATX power supply like I previously mentioned. — Kokachi, Aug 13 '21 at 15:15

score 16 · Accepted Answer · answered Aug 13 '21 at 14:42

The main bulk storage capacitor is rated at 220 volts DC: -

This means that the maximum sinewave RMS voltage that can be applied to the input power connector is 156 volts. This means that it is probably only recommended for supply voltages of 120 volts maximum.

Hearth · Answer 2 · 2021-08-13T14:57:38.043

11

No, definitely not.

That 220 volt capacitor is a dead giveaway--and it'll really be dead if you hook this up to 230 volts AC! Rectified 230 volt mains is something like 325 volts, which would obliterate that capacitor in short order.

edited Aug 13 '21 at 14:57

answered Aug 13 '21 at 14:42

Hearth

27,177
3
51
115

Really dead ... and yet still live... – Aug 13 '21 at 15:53
@user_1818839 Sorry, what? – Hearth Aug 14 '21 at 00:06
1

@Hearth "live" as in "having line voltage on it". Twere a joke. – hobbs Aug 14 '21 at 03:01

score 10 · Answer 3 · answered Aug 13 '21 at 14:41

It's probably a 110V only model.

I think it very unlikely that they built a universal power supply, then printed some of them with fuse values for 125V. If it were a universal power supply, the fuse would have to be rated for the highest expected line voltage (230VAC) rather than a lower voltage.
