What are the names of power supply connectors in this picture?
Asked
Active
Viewed 79 times
1
-
Almost identical question was posted a few days ago. Can you search for it? – Justme Jun 26 '21 at 14:59
-
You are right. I saw it now. – danyal Jun 26 '21 at 15:16
-
These are not swaged or press fit turret terminals as suggested by duplicate, FYI @Community – Tony Stewart EE75 Jun 26 '21 at 17:51
-
The Vcc one looks like a feed trough capacitor. – winny Jun 26 '21 at 18:36
1 Answers
1
I would call them “bulkhead turrets” or case-mounted turrets or “stand-off and feed-through” power and ground terminals.
But it appears some Mfg’s call them “ Threaded Turret Standardized Terminals”
“ PCB solder pin with threaded feedthru pin” for power ? “Threaded double turret” for gnd..?
Tony Stewart EE75
