This is a spst switch working on 2.4 GHz. I want to replace the inductor and capacitors with microstrip line. What is the easy way to do that?

sajib sn
  • 1
  • 2
  • How wide a band around 2.4 GHz are you using? Which inductors and which capacitors do you want to replace? – The Photon Jun 06 '21 at 16:48
  • Its a switch. When it is on it will pass frequencies from 2.2 to 2.6 Ghz. I want to replace all the capacitors and inductors of the circuit. – sajib sn Jun 07 '21 at 13:54

1 Answers1

2

2.4 GHz is a fairly low frequency when it comes to trying to make useful L or C-equivalents with microstrip structures.

But instead of trying to make direct equivalents, you could consider some other options that will achieve the required functionality.

  • Instead of capacitors C19 and C20, you could make a directional coupler structure that blocks DC while passing your 2.4 GHz signal.

  • Instead of L13, you can work out what length of shorted stub line produces a high impedance at its input at 2.4 GHz.

  • You could do the same for L14, but you'll have to be careful how you terminate it.

You probably can't generate 220 nF of capacitance in a practical microstrip structure to replace C21. But you might be able to find a parallel combination of discrete capacitors that provides low impedance over your signal band, in order to terminate the stub line you're using to replace L14.

The Photon
