I have 2 DC sources 12V and 5V, I want to switch them using one switch as shown on scheme. I used here 2 diodes to isolate circuits and it works fine on simulation, but in real scheme 5V (actually rather 4.7V from USB) becomes 5.4V. How can I make circuits run independent (ie. they do not affect each other) in this case?

enter image description here

Simulation with open/closed switch - works fine on simulation but not in reality

enter image description here

schmidt9
  • 105
  • 3
  • 2
    Why not simply use a DPST switch? – Unimportant Apr 24 '21 at 18:50
  • @Unimportant yeah it's a good point, but in real schema I have an `SPDT Centre Off` with an another circuit on the second switch position, so I have to bind these two circuits on the remaining position – schmidt9 Apr 24 '21 at 19:13

1 Answers1

2

schematic

simulate this circuit – Schematic created using CircuitLab

Figure 1. Using a single-pole normally-open switch to select '5 V' or 12 V supply.

  • SW1 open: 5 V is supplied to the load via D1. A silicon diode will drop 0.7 V. A Schottky diode will drop about 0.3 V.
  • SW1 closed: 12 V is supplied to the load. D1 prevents backfeed into the 5 V power supply.

schematic

simulate this circuit

Figure 2. Switch to disconnect two loads.

  • SW1 will disconnect the common return from both loads to the common ground at the power supplies.
  • D1 prevents V1 back-feeding into V2 when SW1 is open. It will cause a voltage drop in normal operation as described above.

This isn't an elegant circuit. Switching negatives in a negative ground circuit can lead to all sorts of confusion. It is, however, common on automobile circuits.

Transistor
  • 168,990
  • 12
  • 186
  • 385
  • Sorry if I was unclear - 2 circuits have 2 different loads, they should run simultaneously not in turn if the switch is closed and stop if the switch is open – schmidt9 Apr 24 '21 at 18:25
  • Loads are represented here by 2 voltmeters – schmidt9 Apr 24 '21 at 18:33
  • Are the sources battery or regulators? Can the 5 V regulator be fed from the 12 V source? – Transistor Apr 24 '21 at 18:39
  • Sources are 2 batteries here, please see I added Gif picture – schmidt9 Apr 24 '21 at 18:42
  • 1
    See the update. See also how I've drawn the schematic with higher voltages at the top so that current flows from top to bottom and circuit reads naturally from left to right. See [rules-and-guidelines-for-drawing-good-schematics](https://electronics.stackexchange.com/questions/28251/rules-and-guidelines-for-drawing-good-schematics) if you're interested in improving. – Transistor Apr 24 '21 at 18:46
