Having read this app note (and a few others) and quite a number of TVS datasheets, I came across one that is bugging me a bit.

All of the TVS datasheets that I have read so far describe the the following concept (below curve is for a unidirectional TVS, but the same principle applies for a bidirectional TVS):

TVS curve

Thus, to generalize, the following seems to always be true:

\$V_{RWM} < V_{BR} < V_{CLAMP} \$

Then I read the datasheet of the Vishay XMC7K24CA and saw this:

TVS specs

From that table, \$V_{CL, max} < V_{BR, min}\$ (and \$V_{BR, max}\$ for that matter). This does not correspond with the general TVS curve above. How is this possible?

EDIT: Yet another datasheet (DIODES DESD18VS1BLP3) that shows the same:

TVS specs 2

I am definitely misunderstanding something here...

wave.jaco
  • 655
  • 6
  • 19
  • 1
    It can happen. I think it's called "snapback". Google app notes about that. There are also two terminal thryistors that take this to the extreme by breaking down to conduct at a very low voltage to crowbar. – DKNguyen Apr 08 '21 at 03:56
  • Take a look at figure 5 of the DIODES datasheet. This is where the higher breakdown voltage at 1mA comes from i would assume. Maybe somebody can explain the graph? – Lars Hankeln Apr 08 '21 at 04:41
  • Found a good article regarding the snapback described above: https://blog.semtech.com/tvs-its-just-a-diode-right-part-two – Ste Kulov Apr 09 '21 at 01:24
  • This is indeed the "snapback" effect (a.k.a. thyristor-like characteristic) and seems to be quite common in some TVS devices. I learned something new today :) – wave.jaco Apr 09 '21 at 03:50

1 Answers1

5

This device has a thyristor-like latching characteristic. Here is a simulation of the SPICE model supplied by the manufacturer:

enter image description here

Spehro Pefhany
  • 376,485
  • 21
  • 320
  • 842
  • 1
    Thanks. This is indeed a thyristor-like characteristic (also called "snapback") of the device. I first had to do some reading to understand this, but now it all makes sense. – wave.jaco Apr 09 '21 at 03:48
  • The datasheet is less than helpful and I couldn't find any more information from [Vishay](https://www.vishay.com/diodes/protection-tvs-esd/xclampr/) on it, other than the SPICE model. They also don't appear to use the "snapback" term, but it's definitely a useful addition to the lexicon, thanks to @DKNguyen for that. – Spehro Pefhany Apr 09 '21 at 03:57
