For example, in the circuit below there are 5 diodes constant-voltage-drop diodes, I could have 2^5 circuits to solve. Is there something I'm not paying attention to, that would greatly simplify this problem?

schematic

PS: The S1 switch is closed. Problem is asking for Vx.

Thanks!

SamGibson
  • 17,231
  • 5
  • 37
  • 58
Leon Held
  • 65
  • 3
  • This conversation has been [moved to chat](https://chat.stackexchange.com/rooms/120890/discussion-on-question-by-leon-held-how-to-even-start-solving-multi-diode-proble). – SamGibson Mar 15 '21 at 18:01

1 Answers1

3

Is there something I'm not paying attention to, that would greatly simplify this problem?

Just start simply.

Ask yourself questions about (say) diode D2 which I've marked nodes on called A and B: -

enter image description here

The question you should ask is this: could voltage B be greater than voltage A. Think about it - is it possible that B is greater than A? If you conclude it can't be then you can remove diode D2 from the circuit.

Then ask questions about the likely voltages either side of D4 and simplify the circuit this way. What about D3 - could it be conducting current given its direction and position in the circuit?

Use your eyes and brain.
