How to create a delayed clock pulse, then return to regular clock cycles

Question

I am attempting to configure an LCD with just IC chips and I've been having problems. I've worked out that the main problem I am having is in the initialization of the lcd. It needs a goodly amount of time to initialise, and then in needs a couple of more configuration instructions.

I would like to give the lcd time to initialise at startup, and then change to a regular clock pulse after 3 delays. So rather than the regular clock pulse (shown in red) 3 long pulses, then back to the regular 555 spacing (shown in blue).

Is there anyway to do this using a combination of IC chips? The delay on the bottom of the clock cycle could be the same long delay, the off time isn't really relevant.

You can do this with one "IC chip", if that chip is a microcontroller. That's really the way to go for applications like this. — Elliot Alderson, Mar 05 '21 at 13:18
It works on the rising edge, and the distance between the falling edge and the next rising edge. (In blue you can see they are short just like the timer. — Rick Dearman, Mar 05 '21 at 15:37
I'm doing this as an exercise in not using a microcontroller. — Rick Dearman, Mar 05 '21 at 15:38

score 1 · Answer 1 · answered Mar 05 '21 at 13:24

The blue trace is one output pulse every 2.5 input pulses, not one every three. This would take a lot of gating to decode.

For 1-out-of-3, consider the CD4017 Johnson counter. If you OR gate or diode-OR together outputs 1, 4, and 7, that is the blue trace. Output 8 inhibits counting and addresses a mux that switches from the output of the OR gate to the red signal (the 4017 clock input). Not elegant, but functional.

Florian · Answer 2 · 2023-05-12T14:41:11.537

0

You can use a sequencial timer like in 9.2.4 of ne555 datasheet (Texas instruments) to control two MOSFET (like 2n7000) who switch between two circuit R es Capa and Diodes as input of your ne555 Clock. Or just change the voltage of the Ctrl (ie: 8/10 of VCC) pin of your clock to increase the duty cycle and lower the frequency.

edited May 12 '23 at 14:41

answered May 12 '23 at 14:13

Florian

11
3
