Consider the following PCB.
I notice some motherboards have such wavy tracks. Are there any purposes? Or it is there merely for artistic purposes?
Asked
Active
Viewed 52 times
0
-
1Matched-length traces are very much not artistic. Either these are differential pairs, or they are matched length for timing purposes. – Ron Beyer Feb 03 '21 at 17:31
-
@RonBeyer: Thank you. It is nice to know this. :-) – Second Person Shooter Feb 03 '21 at 18:29
-
I see only one differential pair in the image. These are most definitely done to match lengths. – DerStrom8 Feb 03 '21 at 23:57
