I try to study the output impedance of a JFET amplifier biased by a current source, but I can't do it.

I know how to determine the output impedance of a JFET amplifier polarized by a voltage divider, but I am hampered by the current source.

How can I do it?

schematics

SamGibson
  • 17,231
  • 5
  • 37
  • 58
Vincent
  • 675
  • 4
  • 11
  • 1
    Start by determining the output impedance of **only** the current source. Assume that the collector of the NPN is connected to a DC voltage source with value Vcc. Draw the small signal equivalent model and determine the impedance when looking into the collector. – Bimpelrekkie Jan 25 '21 at 21:18
  • I agree with Bimpelrekkie - once you determine the impedance of the current source, then replace the current source with its impedance, and you got a much simpler circuit to work with :) As a hint to make your life easy: sometimes it helps to start with idealized components first. How about you see what happens if the current source would be an ideal current source. That'll give you a limiting "best case". Then you can replace the current source with its opposite (the worst current source ever): an ideal voltage source. That's another limiting case. Finally, look at the non-ideal source. – Kuba hasn't forgotten Monica Jan 25 '21 at 22:06
  • Is this answer gives you any help? https://electronics.stackexchange.com/questions/342859/bjt-common-base-output-resistance-derivation/342989#342989 and this https://electronics.stackexchange.com/questions/265046/calculation-of-output-impedance-of-ce-emitter-bias-configuration-unbypassed-wi/276764#276764 – G36 Jan 26 '21 at 14:53
