Below is LTspice simulation in which this error occurs.
The error is Unknown subcircuit called inc xu1 n001 n003 op opamp
How do I fix this error?
Asked
Active
Viewed 1,770 times
1
Voltage Spike
- 75,799
- 36
- 80
- 208
Muhammad Sohaib
- 11
- 2
-
With no partnumber on the schematic shown, are you sure you applied a model to the opamp? If you used one of the Generic/Universal models, you may have to specify the actual opamp characteristics, or supply a component spice model before the simulation can run – Luke Gary Jan 21 '21 at 20:06
1 Answers
3
You have no model for the opamp, every component needs a model:
add the line .lib opamp.sub for further reading on adding models see these links
