Full diagram:
What does the circle with two oblique lines inside it represent?
It's an Emmeti Termec thermostat
Asked
Active
Viewed 182 times
2
Robert Lee
- 205
- 1
- 5
-
I'd guess it's a chiller if you're using the thermostat to control cooling connect the cooling machione there. – Jasen Слава Україні Dec 19 '20 at 23:13
-
what does the instruction manual say about the connections to terminals `2` and `3`? – jsotola Dec 20 '20 at 00:28
-
I wonder if its meant to be a mercury tilt switch – Kyle B Dec 20 '20 at 23:20
