What is this glassy black bulge on a keytar button chip?

Question

I'm disassembling a non-functioning toy keytar. This is the chip behind a couple buttons, including an on/off button. What could the black, glassy bulge component be?

score 5 · Accepted Answer · answered Dec 12 '20 at 15:54

5

It is an on board IC chip bonded directly to the board with an epoxy blob protecting it. Common in low cost assembly.

answered Dec 12 '20 at 15:54

RoyC

8,418
6
25
40

Thanks a lot Roy! – Anna Dec 12 '20 at 15:56
Yep... In the biz we call this 'die bonding' – Kyle B Dec 12 '20 at 17:55
