I need the datasheet of an SMD component, on which I can read

74YH
S21B

The chip is about 3mm x 3mm and, given its position on the board, has likely something to do with voltage regulation (but I can't be 100% sure). It has 8 leads. Please see the attached picture if that helps.

the component to identify is marked 74YH S21B

I have already explored the component-identification procedures proposed in the following post:
How do I identify SMD components? (or how do I identify any component)
but nothing clear came out (at best, hundreds of potential results...).

SamGibson
  • 17,231
  • 5
  • 37
  • 58
Bru
  • 173
  • 3

1 Answers1

5

Very probably an LM3488, a DC/DC converter controller IC; those are marked S21B. The top line of the markings varies.

Not entirely sure, though.

ocrdu
  • 8,705
  • 21
  • 30
  • 42
  • 3
    I think you are correct e.g. [OP's photo](https://i.stack.imgur.com/LcUOI.jpg) shows pins 4 & 5 connected, which fits with that IC you identified (pin 4 = AGND, pin 5 = PGND) and pin 1 for that IC is I_SEN which we expect to be connected to a low value resistor - and we *do* see it connected to a 0.1 ohm resistor in the photo. The capacitor & resistor in the lower left of the photo, would match the RC network expected to be connected to pin 2 (COMP). Some traces (and more of the surrounding components) aren't visible in the photo, but on the supplied info from the OP, this get my vote :-) – SamGibson Nov 19 '20 at 12:25
  • 1
    Thanks, FYI I find all the components about it making a SEPIC, so this makes a lot of sense! – Bru Nov 19 '20 at 15:19
