[Apologies in advance for possible misuse of terminology. I don't have any formal education in EE and am mostly self taught, so I may be lacking in some fundamentals.]
I am trying to design a discrete VCO (for modular synthesizer) using only transistors (2n3904/06 BJT and 2n5457 JFET) and passive components. The architecture is pretty typical for a synth VCO including expo converter, sawtooth core, and shapers for the other waveshapes. Frequency of the output waveforms is intended to cover lower range (1/1000 Hz - 20 Hz) and audible range (20 Hz - 50 kHz) enabling the VCO function as both an audio source and modulation source.
The issue that I am currently having is with the sawtooth core: the output waveform includes an unwanted DC offset by what appears to be some function of the charge current/frequency; at lower frequencies this offset is negligible but around 20 kHz it increases to as much as 500mV. In addition, the amplitude of the waveform seems to change (or the peak and trough are shifted by unequal amounts). The only effect on the signal as an audio source is a slight decrease in volume [with the offset contributing no perceivable change], however when used as a modulation source to vary the frequency of another 1v/oct oscillator the result is up to half an octave of unwanted pitch shift in the carrier waveform.
The LTspice simulation is not accurate to real life and even required several adjustments to cause oscillation, however it does demonstrate the offset issues. Offset of the waveform viewed from the node at the capacitor lead increases by about 70mV at the peak and 100mv at the trough when the frequency is swept from 10kHz to 20kHz. This signal is also amplified by the JFET input amplifier (I can't get this part of the circuit to work in LTspice), further increasing the offset at the final output.
JFET J1 is used as high impedance buffer, intended to buffer the voltage over the capacitor and nothing else; however it seems impossible to find a configuration that avoids creating a path for the charge current to enter as well. The same goes for J3. My guess is that a portion of the charge current enters the JFETs superimposing a DC offset on both the schmitt trigger input (base of Q1) and the final output signal (collector of Q7).
Any ideas on how to get rid of this offset and/or on what exactly is causing it?
One solution I have proposed is to mirror the charge current and subtract its voltage drop over a resistance from the buffered output at J1 and the final output as a sort of offset compensation. I have not had any luck with this approach, but perhaps I have implemented it incorrectly. Another solution is to AC couple the outputs, but I have not had any luck with this either.
I've spent about a week trying to resolve this with little success, so any help would be greatly appreciated. Thanks in advance.
