I'm trying to understand the operation of a single coil magnetometer (marketed as "fluxgate", but with only a single coil). I've backed out the schematic as shown. The coil is driven by a 17kHz oscillator (not shown other than as "oscillator").

I'm stumped on the part I've called U4. It appears to be a SOT-143 device with the marking "E9" on the top. There is no continuity between any of its 4 pins to the others. Sadly the diagram doesn't lend many hints either - I was initially leaning to an NPN RF transistor, but the pinouts/functionality don't make sense. Any thoughts would be appreciated. Photo of the part included with U4 circled.

Schematic

U4

U4 Numbered

geo_leeman
  • 85
  • 6
  • 2
    Are you sure C7 is not Vcc and GND? Can you add pin numbers? If it is, a long shot would be this guy: http://www.natlinear.com/uploadfiles/2014/LN/LN3526_C.pdf – winny Nov 10 '20 at 18:13
  • 1
    @winny Confirmed - from what I can tell those are solely connected to pins 1, 4 of the mystery device. See the updated photo with a close up with tracks clearly shown. – geo_leeman Nov 10 '20 at 19:29
  • 1
    Thanks! Johns answer makes sense. – winny Nov 10 '20 at 21:50

1 Answers1

5

The voltage divider divides the 5 volts in half and makes what you have labeled as "2.5 V" as an analog reference so that your signal can swing positive and negative. You might redraw your circuit showing this as your ground, and it might be easier to wrap your mind around it. I believe the "mystery part" is a diode array, possibly a BAS4002A from the marking. The idea is that the circuit will saturate the inductor in both directions from a symmetrical signal from the oscillator, but if a local magnetic field is aligned with the inductor core, it is added to the field produced by the coil in one direction (and subtracted in the other) so that it will not be saturated symmetrically. This will produce a bias on your integrator at R11.

Good luck!

John Birckhead
  • 10,524
  • 1
  • 11
  • 27
  • 1
    After probing with a meter this appears to be correct! I'll order one and swap it to verify/look at the part identifiers, but I believe you nailed it @John Birckhead - great job! Will update with more details on what we verify. – geo_leeman Nov 10 '20 at 22:48
