Trying to find out what this one is has been a real head-scratcher. Google leads me down numerous rabbit-holes to dead ends. And I see 1 or 2 for sale on eBay, but apparently they have no idea what it is either. Insight, help, moral support would all be greatly appreciated - thanks! Fairchild HL41109QB

John - Head Miner - PartsMine
  • 21
  • 2
  • What are the devices used in? Where did you get them or see them? – Andy aka Sep 13 '20 at 16:57
  • This question is the top google hit for HL41109 so clearly it is not a commonly known part. There is no reason it can't be a custom or customer configured part. If you are trying to replace them @Andy aka has the right suggestions, if you are trying to price or market them good luck. – crasic Sep 13 '20 at 17:23
  • The IC's in OP's photo have especific codes written in: "176-148" (for that one fabricated in 7532), "176-090A" (fabricated 7631), and the one selling in ebay has "176-221" (fabricated 7719). I would preffer to be out of this hand; if I really had to bet, I would bet that this is a mask ROM. – mguima Sep 13 '20 at 17:53
  • If this is a custom marked version of a part with a public datasheet, you might find it in https://bitsavers.org/components/harris/ perhaps in the 1975 databook. Unfortunately they don't seem to have die photos. If this was a fully custom ASIC with no public datasheet, there is no way to identify it. – MarkU Sep 13 '20 at 22:11
  • @Andy - As to where I got them, that’s a really good question... My company has been buying and selling scientific, medical and industrial surplus for over 20 years. I squirreled these away sometime ago and am thinking its government lab related surplus or maybe really old Hewlett Packard material. – John - Head Miner - PartsMine Sep 14 '20 at 21:50
  • @crassic I am trying to price them for inclusion on our electronics parts website. I am slowly cataloging a mountain of stuff and uncovered these recently. Thanks for the ‘good luck’ it’s much needed and appreciated! – John - Head Miner - PartsMine Sep 14 '20 at 21:52
  • @MarkU - Thanks for the link to bitsavers, will definitely check it out! – John - Head Miner - PartsMine Sep 14 '20 at 21:55
  • @mguima - Thanks, I’m going to start learning and getting more familar with ROMs from that era. Lords knows that I’m certain run across more of this type of stuff. – John - Head Miner - PartsMine Sep 14 '20 at 22:00

0 Answers0
