UPS in front of an ATS for generator protection

Asked Jul 19 '20 at 13:53

Active Jul 19 '20 at 15:48

Viewed 65 times

At the countryside house there is this setup:

And I am trying to protect the generator and house load from brief ~ 1s power outages like so:

It works fine in normal conditions. Trouble is when I turn off the UPS output as to simulate an outage the ATS won't start the generator. I have just thought that maybe by turning off the UPS output then Live and Neutral are left floating and that could somehow impact ATS outage detection?

edited Jul 19 '20 at 15:48

winny

13,064
6
46
63

asked Jul 19 '20 at 13:53

kellogs

1,044
9
18

1

Put the UPS between ATS and house maybe? – Andy aka Jul 19 '20 at 14:08
Are you planning to support fridge, freezer and cooker with the ups? – Solar Mike Jul 19 '20 at 14:15
@Andyaka I have seen that setup on the interwebs, but will it prevent the generator from starting up during a brief outage? – kellogs Jul 19 '20 at 14:27
@SolarMike yes sir, multiple fridges and freezers. – kellogs Jul 19 '20 at 14:28
