4 Pins Potentiometer (Replacement)

Question

I am trying to repair a very expensive manlift joystick.

It has 4 pins total, three like a normal rotary potentiometer and then a fourth across from the other three pins.

It is PEO 284-04378 Type EJ pot. It has another number stamped "5k 1342"

The company not produce it more and I'm looking if there is something similar to do the same work I was looking for P271-DS21BR10K but is 10K would that affect?

Please correct your question title - ALLCAPS is not appropriate. — Solar Mike, Jun 11 '20 at 23:41

score 1 · Accepted Answer · answered Jun 12 '20 at 00:42

It seems almost certain that you are looking for a "center tapped potentiometer" If you search using that term, you should be able to find a replacement. It seems likely that the pictured pot is 5K ohms. You may or may not be able to use a different value. You can not find the correct value, you could try a different value and see what happens. Trying 10K rather than 1K would seem to me to be the safest thing to try if you can not find 5K.

score 0 · Answer 2 · answered Jun 11 '20 at 23:47

0

It may affect. But you can use any other 10K POT which would fit in, and of course with the right connections.

answered Jun 11 '20 at 23:47

Fredled

1,820
9
17

Thanks, I will still waiting if someone can know about a similar potentiometer. – John Batista Jun 11 '20 at 23:49

score 0 · Answer 3 · answered Jun 13 '20 at 02:20

0

enter image description here

I found that one that seem to have the same number and is 5k too I hope that work, thanks (https://i.stack.imgur.com/8Duep.png)

answered Jun 13 '20 at 02:20

John Batista

23
3
