Can anyone tell me what are these smt devices. Especially the one with square drawn at centre
Asked
Active
Viewed 53 times
0
Jayant Nagle
- 11
- 1
-
Measure the resistance of them (in circuit) with a DMM. They should all be zero ohms. In which case they are zero ohm links. – Warren Hill Jun 04 '20 at 12:37
1 Answers
5
They are zero ohm links. Maybe mainly used as jumpers on this single sided board to allow for a track to run under them, but they have other uses, see What is the usage of Zero Ohm & MiliOhm Resistor?
