How do I work out the correct PWM frequency for my application (motor)?

Asked May 21 '20 at 13:44

Active May 21 '20 at 14:22

Viewed 60 times

I am working on a project and want to drive a motor with a 12V PWM signal (Motor connected to 12V and the Motor- net on the diagram).

I have it working, however i'm not sure how to work out the optimum frequency for my PWM to operate at for the motor i'm using. It's a brushed DC motor. I have attached the only information I have on the motor in case that helps.

Any advice or input is welcome. Thanks in advance.

Circuit Diagram

Motor Spec

edited May 21 '20 at 14:22

asked May 21 '20 at 13:44

Orca_StackOverflow

3

You can't drive a brushless motor that way. If it spins, it is brushed. – DKNguyen May 21 '20 at 13:46
Thanks, for the correction. I wrote the wrong thing. – Orca_StackOverflow May 21 '20 at 14:22
Question has been edited to correct. – Orca_StackOverflow May 21 '20 at 14:23
Read this old case: https://electronics.stackexchange.com/questions/242293/is-there-an-ideal-pwm-frequency-for-dc-brush-motors – May 21 '20 at 14:26
2

Voting to close as a duplicate of: [Is there an ideal PWM frequency for DC brush motors?](https://electronics.stackexchange.com/questions/242293/is-there-an-ideal-pwm-frequency-for-dc-brush-motors) – May 21 '20 at 15:11
you want it high enough to avoid audible kick noise and low enough to prevent capacitance turning power into heat. – dandavis May 21 '20 at 17:30

How do I work out the correct PWM frequency for my application (motor)?

0 Answers0
