VHDL - big difference in schematics between integer with and without range

Question

I just discovered something that I would like some expert to comment on.

CODE EXAMPLE A:

entity PipelinePoc is
    Port ( clk : in STD_LOGIC;
           led : out std_logic_vector(0 downto 0)
           );
end PipelinePoc;

architecture Behavioral of PipelinePoc is

begin
process(clk) is
variable x : integer;
variable y : integer;
begin

    if rising_edge(clk) then
        if(x = 299)
        then
            x := 0;
            if(y >= 500)
            then
                y := 0;
            else
                y := y + 1;
            end if;
        else
            x := x + 1;
        end if;
        if((x+y) / 49 > 200)
        then
            led(0) <= '1';
        else
            led(0) <= '0';
        end if;

    end if;
    end process;
    end Behavioral;

CODE EXAMPLE B (Only difference is limited range on the integers):

    entity PipelinePoc is
        Port ( clk : in STD_LOGIC;
               led : out std_logic_vector(0 downto 0)
               );
    end PipelinePoc;

    architecture Behavioral of PipelinePoc is

    begin
    process(clk) is
    variable x : integer range 0 to 1280 := 0;
    variable y : integer range 0 to 960 := 0;
    begin

    if rising_edge(clk) then
        if(x = 299)
        then
            x := 0;
            if(y >= 500)
            then
                y := 0;
            else
                y := y + 1;
            end if;
        else
            x := x + 1;
        end if;
        if((x+y) / 49 > 200)
        then
            led(0) <= '1';
        else
            led(0) <= '0';
        end if;

    end if;
    end process;
    end Behavioral;

SCHEMATICS FOR EXAMPLE A:

SCHEMATICS FOR EXAMPLE B:

I would expect some difference between the example a with no range, assuming 32 bit may be representing the x and y values while the range 0 to 1280 can be represented with only 11 bit.

But the difference between the corresponding schematics is so huge, that either: - I may be missing some bug in my example be, allowing for the compiler to greatly simplify the logic - Or the FPGA has some small units that can do operations of a certain size (I am using a Basys3 board).

Can anyone explain why I end up with these very different schematics with only adding integer ranges?

Thanks

The difference is not the integer range, but you setting the integer to 0 initially. Which renders your counting thingie completely non-functional, as schematics B might slightly indicate :D — Marcus Müller, May 02 '20 at 10:26
Well the compiler may realise that if((x+y) / 49 > 200) will never be true and just skip it all, yes. And maybe the compiler can only be certain of this based on the integer range. I will go make a new test with something that the compiler cannot leave out. Thanks :) — Stephan Møller, May 02 '20 at 10:29
ah by the way, I'm hopeful the synthesizer recognizes that (x+y)/49 > 200 can be simplifed to x+y > 9800, but you really better write it like that, in case you're missing some integer semantic corner case, where the synthesizer will actually have to implement a divisions. [Division is the most complicated to implement basic arithmetic function](https://electronics.stackexchange.com/questions/280673/why-does-hardware-division-take-much-longer-than-multiplication/280695#280695), by far. If you can at almost any cost avoid it:don't divide to actual variables(not constants,these can be optimized). — Marcus Müller, May 02 '20 at 10:32
Thanks, Marcus. I updated the post. I just love this game of hunting down complexity. I am new to all this fpga. Thanks for your comment. If you post an answer (just like "The compiler optimized it all away in example b) then I can go accept it as the right answer. — Stephan Møller, May 02 '20 at 10:39
Hey, I think your edit to your question would actually be an answer to your question! Self-answering your questions is actually very appreciated here, so do just take the content of your edit, and cut&paste it to the answer field! That will allow you to mark the question answered, and us to upvote the answer :) — Marcus Müller, May 02 '20 at 10:55

Stephan Møller · Answer 1 · 2020-05-02T11:51:52.950

As Marcus Müller pointed out, the compiler can ignore all logic as if((x+y) / 49 > 200) will never render true with the limited integers. I have made a new test with some logic that the compiler has to respect:

Example A V2:

entity PipelinePoc is
    Port ( clk : in STD_LOGIC;
           led : out std_logic_vector(0 downto 0)
           );
end PipelinePoc;

architecture Behavioral of PipelinePoc is

begin
process(clk) is
variable x : integer;
variable y : integer;
begin

if rising_edge(clk) then
    -- STEP 0: Adjust pixel if overflow
    if(x = 299)
    then
        x := 0;
        if(y >= 500)
        then
            y := 0;
        else
            y := y + 1;
        end if;
    else
        x := x + 1;
    end if;
    if((x+y) = 70)
    then
        led(0) <= '1';
    else
        led(0) <= '0';
    end if;

end if;
end process;
end Behavioral;

Schematics for A v2:

Example B V2:

entity PipelinePoc is
    Port ( clk : in STD_LOGIC;
           led : out std_logic_vector(0 downto 0)
           );
end PipelinePoc;

architecture Behavioral of PipelinePoc is

begin
process(clk) is
variable x : integer range 0 to 1280;
variable y : integer range 0 to 1280;
begin

if rising_edge(clk) then
    -- STEP 0: Adjust pixel if overflow
    if(x = 299)
    then
        x := 0;
        if(y >= 500)
        then
            y := 0;
        else
            y := y + 1;
        end if;
    else
        x := x + 1;
    end if;
    if((x+y) = 70)
    then
        led(0) <= '1';
    else
        led(0) <= '0';
    end if;

end if;
end process;
end Behavioral;

Schematics for B v2:

CONCLUSION:

Compiler was clever enough to figure that the logic could be totally left out.

Synthesis is good at that. That's part of why it's good to get things right in simulation first; THEN synthesise. — , May 02 '20 at 17:31
