ID a green ceramic component from a tachometer?

Question

This component is from a 1960-70 vintage boat tachometer.

It's about 1.25" long. It generates not a single reading on my 11-function multimeter (including capacitance). I may have fried it removing it from the circuit board.

Thanks for any help.

1uF 10% 250V. Per comment on previous answer except now we can see the value. — , Mar 09 '20 at 22:15

score 3 · Answer 1 · answered Mar 09 '20 at 21:38

3

It might be a 1uF +/-10% 250V film capacitor.

Eg. (0.1uF cap with similar markings from this website

Check your meter's capacitance range on a known-good part if you don't use it frequently.

answered Mar 09 '20 at 21:38

Spehro Pefhany

376,485
21
320
842

excellent. Thank you. Checking now! – Bill Catlin Mar 09 '20 at 21:48
1

And you called it. .95uF – Bill Catlin Mar 09 '20 at 22:34

score 0 · Answer 2 · answered Mar 09 '20 at 23:37

0

The capacitance might be to small for most multimeters that I know of. I would recommend getting a good quality dedicated bench-top capacitance meter.

Note: I’ve had much better experience and accuracy with bench-top meters than with cheap handheld meters(I have also had a similar Experience with bench top oscilloscopes cheap handheld scopes are just not worth it.) however this post does not discriminate against owning a good handheld multimeter. (:

answered Mar 09 '20 at 23:37

MR.TECH

11
3

Thanks for the advice. In this case it was operator error. I'd missed the fact that the meter has two slots for cap leads. It only goes to 20uF, but that's enough in this case. – Bill Catlin Mar 09 '20 at 23:47
