Question:
Normally I find Karnaugh Map of an expression from its truth table, but can we have Logic operation on two Karnaugh Maps ?
Update:
Asked
Active
Viewed 62 times
2
-
I didn't read carefully over everything. Seems like there should be a rigourous way to do it. I'm personally more interested in the case where your two karnaugh maps have different numbers of inputs. – DKNguyen Jan 31 '20 at 00:31
-
@DKNguyen I think this would also work, for example 2 inputs and 1 input, then we get a 2 by 4 K-Map – Ethan Jan 31 '20 at 00:47
-
It should work, but it seems to be a lot of work. I'd find it easier to populate the truth table **and** then populate the kmap. – StainlessSteelRat Jan 31 '20 at 20:04
