I need to make a USB communication cable for the Zebex Z-6170 barcode reader. I found a reader pin-out description but I can't understand it. It is about powering the reader from USB and pin 1 (USB Power) and 2 (+ 5V).

My guess is that USB Power is Vbus and pin 2 (+5V) is possibility of connecting an external power supply, but I'm not sure. Below is a link to the description of the barcode reader pin-out

Z6170 Buyers Guide

I suspect that the scheme should look like this:

Scanner - USB
Pin 1 - Pin 1 (power)
Pin 3 - Pin 2 (Data -)
Pin 8 - Pin 3 (Data +)
Pin 5 - Pin 4 (GND / VSS)

but I'm not sure.

mlik
  • 11
  • 1
  • power is pin 2, the rest of the wiring scheme looks correct ... don't forget that the scanner has a 10 pin jack, so if you use an RJ45 connector, then you are connecting to pins 2 through 9 – jsotola Jan 19 '20 at 08:50

2 Answers2

1

This is the table in the buyers guide:

Z-6170 buyers guide: table

It specifies 10P10C connector. For an 8P8C connector the mapping would be

  • RJ45 pin 1 - +5V
  • RJ45 pin 2 - D-
  • RJ45 pin 4 - GND
  • RJ45 pin 7 - D+

An RJ45 connector can be inserted into such an RJ50 socket, the pin counting is then reduced by one.

This connector is also used by some vendors, [...] allowing an 8P8C plug to be inserted to their 10P10C socket for most applications.

Source: Wikipedia

try-catch-finally
  • 1,254
  • 3
  • 19
  • 37
1

I send information directly from technical support zebex. Note the additional barcode scanner pinout connection:

Scanner (RJ50) - USB
1-2 (USB Power, + 5V) - 1
6-7 (TxD - RxD)

enter image description here

mlik
  • 11
  • 1
